Thevenin Impedance Networks for Spice Simulation Using Analog Behavioural Modelling

Year : 2024 | Volume : 14 | Issue : 03 | Page : 39 46
    By

    K. Bharath kumar,

  1. Former Engineer, Oki Electric Company, Semiconductor Technology Lab, Hachioji,, Tokyo 193, Japan

Abstract

PSPICE/OrCAD software analog behavioral modeling (FREQ) option is used to obtain equivalent circuits for Thevenin equivalent resistance to be used for three types of applications for different circuits (other different networks with these Thevenin models at DC), and Spice files are described to simulation circuits with AC analyses. Three different applications are useful in linear integrated circuits using DC Thevenin resistance of two networks are considered. Firstly, the DC Thevenin resistance is converted to AC Thevenin impedance with a complex multiplication factor using analog behavioral modeling of PSpice. This impedance is connected across the required terminals of an electronic circuit and analyzed. An impedance with a value equal to complex AC voltage equivalent to AC Thevenin equivalent is connected across the required terminals (with equivalent impedance=AC voltage/AC) and verified. The current through this impedance is converted to the desired AC voltage with a complex number and a third circuit is analyzed with these modifications. Two SPICE files which are self-explainable are given with examples. The FREQ option, which was not previously available in SPICE 2G versions, is used to obtain Thevenin modifications for impedance and AC voltages. This Analog behavioral option can be used in polar or rectangular formation of complex numbers. The frequency-dependent (independent) immittances can be simulated using this option. These two facilities are (could be) used in the examples described.

Keywords: Analog passive network theory, non-linear circuits, complex variables, circuit analysis and modeling, solid state circuits, microwave circuits, VLSI technology

[This article belongs to Journal of VLSI Design Tools and Technology ]

How to cite this article:
K. Bharath kumar. Thevenin Impedance Networks for Spice Simulation Using Analog Behavioural Modelling. Journal of VLSI Design Tools and Technology. 2024; 14(03):39-46.
How to cite this URL:
K. Bharath kumar. Thevenin Impedance Networks for Spice Simulation Using Analog Behavioural Modelling. Journal of VLSI Design Tools and Technology. 2024; 14(03):39-46. Available from: https://journals.stmjournals.com/jovdtt/article=2024/view=183608


Browse Figures

References

  1. Prigozy S. Novel applications of SPICE in engineering education. IEEE Trans Educ. 1989;32:35–8. doi: 10.1109/13.21160.
  2. Nagel LW. SPICE 2, a computer program to simulate semiconductor circuits. Electron Res Lab Rep ERL-M520, Univ Calif Berkeley SPICE Version 2G User’s Guide. Berkeley, USA; 1975.
  3. Wilson B. Tutorial review trends in current conveyor and current-mode amplifier design. Int J Electron. 1992;73:573–83. doi: 10.1080/00207219208925692.
  4. Bharath Kumar K. Multi two port parameter simulation using PSpice [Technical report]. Semiconductor Research Laboratory, Oki Electric Industry, Japan; 1990.
  5. Rashid MH. SPICE for circuits and electronics using PSPICE. Prentice Hall: Englewood Cliffs, USA; 1995.
  6. Keown J. OrCAD PSpice and circuit analysis. Prentice Hall: Englewood Cliffs, USA; 2001.
  7. Du H, Gorcea D, So PPM, Hoefer WJR. A SPICE analog behavioral model of two-port devices with arbitrary port impedances based on the S-parameters extracted from time-domain field responses. Int J Numer Model Electron Netw Devices Fields. 2008;21:77–90. doi: 10.1002/jnm.670.
  8. Van Valkenburg ME. Network analysis. 3rd ed. Prentice Hall: Englewood Cliffs, USA; 1976. pp. 259–61.
  9. Bharath Kumar K. Methods to obtain a new circuit whose Thevenin and Norton equivalents are functions of two different Thevenin and Norton circuits. Electro Bits Mag. 2023;37–44.
  10. Vladimirescu A, Zhang K, Newton AR, Pederson DO, Sangiovanni-Vincentelli A. SPICE Version 2G user’s guide. Dept Elect Eng Comput Sci, Univ Calif Berkeley: Berkeley, USA.
  11. Bharath Kumar K. Techniques for using SPICE to derive Thevenin and Norton equivalent circuits. EDN Mag, Design Ideas, Online Ed.; 2022.
  12. Jin LM, Chan SP. A unified and efficient approach for determining Thevenin (Norton) equivalent circuits. IEEE Trans Educ. 1989;32:408–10. doi: 10.1109/13.34184.
  13. Holder ME. Thevenin’s theorem and a black box. IEEE Trans Educ. 2009;52:573–5. doi: 10.1109/TE.2008.2010985.
  14. Hongyang Z. Discussion on the Thevenin’s theorem and Norton’s theorem. Proc Int Conf Electron Mech Eng Info Technol. 2011;520–2. doi: 10.1109/EMEIT.2011.6022970.
  15. MicroSim P. Spice & basics, circuit analysis software. User’s Guide, version 8.0; 1997.
  16. Epler B. SPICE2 application notes for dependent sources. IEEE Circuits Devices Mag. 1984;3:36–44.
  17. Bharath Kumar K. Inverse ABCD parameter determination using SPICE. Int J Analog Integr Circ. 2017;3:1–6.
Regular Issue Subscription Review Article
Volume 14
Issue 03
Received 22/10/2024
Accepted 26/10/2024
Published 16/11/2024
