Variables Influencing the Reinforcing Effect of Organoclay in Polymer Nanocomposites


Year : 2025 | Volume : 15 | Issue : 01 | Page : 55-64
    By

    Haydar U. Zaman,

  1. Assistant Professor, Department of Physics, National University of Bangladesh and Institute of Radiation and Polymer Technology, Bangladesh Atomic Energy Commission, Dhaka, , Bangladesh

Abstract

This study examines how several factors affect the mechanical and thermal characteristics, such as tensile strength, tensile modulus, impact strength, thermal decomposition temperature, and Vicat softening point tests of poly(vinyl chloride)/organoclay nanocomposites. The variables included three different organoclay loading levels, three different screw rotation speeds, and three different plasticizer contents. A co-rotating twin-screw extruder was used to create the poly(vinyl chloride)/organoclay nanocomposite via the melt intercalation process. The properties of the nanocomposite were examined in relation to the impacts of organoclay loading, extruder rotor speed, and plasticizer (dioctyl phthalate) with different concentrations. The clay content of 3 weight percent organoclay showed notable improvements in mechanical parameters, such as tensile strength, tensile modulus, and impact strength, with the maximum mechanical test values generally occurring at 100 rpm. In contrast to the other system and the poly(vinyl chloride)/organoclay system, the addition of a 20-weight percent dioctyl phthalate plasticizer system at 100 rpm resulted in greater mechanical properties. Photographs taken using a transmission electron microscope revealed that during melt mixing, the organoclay was partially exfoliated and intercalated when dioctyl phthalate was present. The thermal stability of the nanocomposites was evaluated using thermogravimetric analysis. The thermogravimetric analysis results demonstrated that the thermal stability of the poly(vinyl chloride) matrix was considerably enhanced by the addition of organoclay.

Keywords: Poly(vinyl chloride), organoclay, nanocomposites, mechanical properties, thermal properties

[This article belongs to Journal of Nanoscience, NanoEngineering & Applications ]

aWQ6MTk2ODA4fGZpbGVuYW1lOjllNGIwZmM1LTEtcG5nLndlYnB8c2l6ZTp0aHVtYm5haWw=
How to cite this article:
Haydar U. Zaman. Variables Influencing the Reinforcing Effect of Organoclay in Polymer Nanocomposites. Journal of Nanoscience, NanoEngineering & Applications. 2025; 15(01):55-64.
How to cite this URL:
Haydar U. Zaman. Variables Influencing the Reinforcing Effect of Organoclay in Polymer Nanocomposites. Journal of Nanoscience, NanoEngineering & Applications. 2025; 15(01):55-64. Available from: https://journals.stmjournals.com/jonsnea/article=2025/view=192285


Browse Figures

References

  1. Maniyar K, Jadhav P, Biradar R, Gawande J. An experimental study of process parameters for nanocomposites. NanoWorld J. 2024;10:209–11.
  2. Zaman HU, Hun PD, Khan RA, Yoon KB. Polypropylene/clay nanocomposites: effect of compatibilizers on the morphology, mechanical properties and crystallization behaviors. J Thermoplast Compos Mat. 2014;27:338–49.
  3. Pilar C, Suarez M, Jerome R, Hyosung A, Robert C, Nahas, et al. Polymer-clay nanocomposite coatings as efficient, environment-friendly surface pretreatments for aluminum alloy 2024-T3. Electrochimica Acta. 2018;260:73–81.
  4. Izadpanah R, Rezaei M, Talebi S. Preparation of cross-linked PVC-g-(St-MA) copolymer/organoclay nanocomposites and investigation of chemical characteristics, morphology, thermal, and mechanical properties. J Thermoplast Compos Mat. 2022;35(2):211–29.
  5. Nath AK, Bhaswati S. Electrochemical and thermal properties of polymer-layered silicate nanocomposites for energy storage applications. Polym Polym Compos. 2021;29:547–55.
  6. Kausar A. Physical properties of hybrid polymer/clay composites. InHybrid polymer composite materials. Woodhead Publishing; 2017. pp. 115–32.
  7. Nilanjal M, Virendra K, Jitendra B, Shovit B, Mazumder S, Lalit V. Layered silicate-polymer nanocomposite coatings via radiation curing process for flame retardant applications. Progr Organ Coat. 2014;77:1443–51.
  8. Nekhlaoui S, Abdelaoui H, Raji M. Assessment of thermo-mechanical, dye discoloration, and hygroscopic behavior of hybrid composites based on polypropylene/clay (illite)/TiO2. Int J Adv Manufact Tech. 2021;113:2615–28.
  9. Zaman HU, Beg MDH. Mechanical, thermal, and rheological properties of nano-calcium carbonate/polypropylene composites modified by methacrylic acid. J Thermoplast Compos Mat. 2014;29:189–203.
  10. Zaman HU, Hun PD, Khan RA, Yoon KB. Morphology, mechanical, and crystallization behaviors of micro- and nano-ZnO filled polypropylene composites. J Reinf Plast Compos. 2012;31:323–9.
  11. Shigemitsu M, Atsushi I, Yoshiharu M, Noritaka K, Yoshiyuki N. Structural characteristics and moisture sorption behavior of nylon-6/clay hybrid films. J Polym Sci Part B Polym Phys. 2002;40:479–87.
  12. Wei-Hua Y. The preparation of modified polyamide clay nanocomposite/recycled maleic anhydride polyamide 6 and blending with low density polyethylene for film blowing application. Polym Polym Compos. 2021;29:S631–43.
  13. Nóra H, Szabolcs P, Richárd TV, Béla P. Coupling of PMMA to the surface of a layered silicate by intercalative polymerization: processes, structure and properties. Coll Surf A Physicochem Eng Asp. 2020;601:124979.
  14. Zina V, Denis Mihaela P, Catalina Gabriela S, Constantin R, Raluca G, Cristian Andi N, et al. The effect of polystyrene blocks content and of type of elastomer blocks on the properties of block copolymer/layered silicate nanocomposites. J Alloy Comp. 2014;616:569–76.
  15. Camila R, Ferreira Celso V, Santilli Valérie B, Sandra HP. Relevance of the iron distribution in natural smectite clays for the thermal stability of PMMA–clay nanocomposites. ACS Omega. 2024;34:36579–88.
  16. Hadeel A, Hanan A, Ibraheem, Huda Ghazi N, Ala R, Shaker, et al. Enhancing photoirradiation stability: a review on modification of poly(methyl methacrylate). Al-Nahrain J Sci. 2024;27:32–42.
  17. Linqin T, Chengyuan S, Yu C, Yunchuan X, Xinyue H, Ziyu Y, et al. Influence of biodegradable polybutylene succinate and non-biodegradable polyvinyl chloride microplastics on anammox sludge: performance evaluation, suppression effect and metagenomic analysis. J Hazard Mat. 2021;401:123337.
  18. Margarita M, Sánchez-Valdés S, Sanchez-Espíndola ME, Rivera-López Jesús E. Morphology, mechanical properties, and thermal stability of rigid PVC/clay nanocomposites. Polym Eng Sci. 2011;51:641–6.
  19. Trilica J, Kalendova A, Malac Z, Simonik J. Statement of policy release for publication of SPE Conf Paper. May 6-10, 2001. p. 2162.
  20. Seyyed B, Abdollahi B, Behnaz B, Fatemeh M, Dorrin Mohtadi H, Zahra M. Clay-reinforced PVC composites and nanocomposites. Heliyon. 2024;10:2405–8440.
  21. Nesterov AE, Lipatov YS. Compatibilizing effect of a filler in binary polymer mixtures. Polymer. 1999;40:1347–9.
  22. Privalko VP, Shumsky VF, Privalko EG, Karaman VM, Walter R, Friedrich K, et al. Viscoelasticity and flow behavior of irradiation grafted nano-inorganic particle filled polypropylene composites in the melt state. Sci Tech Adv Mat. 2002;3:111–6.
  23. Sanghyeon P, Changyub N, Sung‑Soo K, Lee Ku K, Hong Gun K, Jin‑Hae C, et al. Colorless and transparent polyimide nanocomposites using organically modified montmorillonite and mica. Sci Rep. 2024;14:10670.
  24. Neeraj K, Chandra M, Arvind N. An investigative study on the structural, thermal and mechanical properties of clay-based PVC polymer composite films. Polymers. 2023;15(8):1922.
