Experimental Investigation into MRR of Polished Zinc Plate with Ultrasonic Vibrations Using Single Pole Magnetic Abrasive Finishing Process

Year : 2026 | Volume : 14 | Special Issue 01 | Page : 428 438
    By

    Arsh Siddiqui,

  • Mragank Sharma,

  • Kheelraj Pandey,

  • Ashwani Sharma,

  1. UG scholar, Department of Mechanical Engineering, Amity University , Lucknow, Campus, Uttar Pradesh, India
  2. Assistant Professor, Department of Mechanical Engineering, Amity University , Lucknow, Campus, Uttar Pradesh, India
  3. Assistant Professor, Department of Mechanical Engineering, Amity University , Lucknow, Campus, Uttar Pradesh, India
  4. Assistant Professor, Department of Mechanical Engineering, Amity University , Lucknow, Campus, Uttar Pradesh, India

Abstract

The present research examines the material removal rate (MRR) in finishing zinc plates on the experimental framework called Single Pole Magnetic Abrasive Finishing Process (SPMAFP) by inducing ultrasonic vibrations. By means of a Flexible Magnetic Abrasive Brush (FMAB) composed of 40% alumina and 60% iron elements, the investigation estimates the effect of key process parameters on surface finishing excellence. An L-16 factorial study design was applied to examine the FMAB speed, working gap, feed rate, and pulse-on time effect on MRR. Statistical examination shows that higher FMAB speed and smaller working gap significantly increases the material removal by increasing magnetic flux concentration and abrasive indentation force. The optimal parameters are 1500 RPM speed, 6mm working gap, 5.5mm/s feed rate, and 7.3 minutes pulse-on time, yielding an MRR of 9.8 mg/min. SEM analysis confirmed the procedure successfully eliminated the surface deficiencies, producing a smooth surface roughness (SR). Ultrasonic vibrations increase the MRR by abrasive particle agitation thus reducing the frictional resistance at the contact surface. The maximum MRR attained without ultrasonic vibration was 6.4 mg/min, but ultrasonic-assisted trials got 9.8 mg/min, indicating a 53% increase in material removal rate. Experimental results closely matched theoretical predictions, validating effectiveness of the chosen process parameters.

Keywords: Flexible magnetic abrasive brush (FMAB), Magnetic abrasive finishing process (MAFP), Material removal rate (MRR), Single-pole magnetic abrasive finishing process (SPMAFP), Surface roughness (SR)

[This article belongs to Special Issue under section in Journal of Polymer & Composites (jopc)]

How to cite this article:
Arsh Siddiqui, Mragank Sharma, Kheelraj Pandey, Ashwani Sharma. Experimental Investigation into MRR of Polished Zinc Plate with Ultrasonic Vibrations Using Single Pole Magnetic Abrasive Finishing Process. Journal of Polymer & Composites. 2026; 14(01):428-438.
How to cite this URL:
Arsh Siddiqui, Mragank Sharma, Kheelraj Pandey, Ashwani Sharma. Experimental Investigation into MRR of Polished Zinc Plate with Ultrasonic Vibrations Using Single Pole Magnetic Abrasive Finishing Process. Journal of Polymer & Composites. 2026; 14(01):428-438. Available from: https://journals.stmjournals.com/jopc/article=2026/view=237339


Browse Figures

References

  1. Shinmura T, Takazawa K, Hatano E, Matsunaga M, Matsuo T. Study on magnetic abrasive finishing. In: CIRP, editor. CIRP Annals – Manufacturing Technology. 1st edition. Paris, France: CIRP; 1990. pp. 325–328.
  2. Singh DK, Jain VK, Raghuram V. Parametric study of magnetic abrasive finishing process. In: Elsevier, editor. Journal of Materials Processing Technology. 1st edition. Amsterdam, Netherlands: Elsevier; 2004. pp. 22–29.
  3. Wang Y, Hu D. Study on the inner surface finishing of tubing by magnetic abrasive finishing. In: Elsevier, editor. International Journal of Machine Tools and Manufacture. 1st edition. Oxford, UK: Elsevier; 2005. pp. 43–49.
  4. Jain RS, Pandey PM. Ultrasonic assisted magnetic abrasive finishing of hardened AISI 52100 steel using unbonded SiC abrasives. In: Pandey PM, editor. International Journal of Refractory Metals and Hard Materials. 1st edition. Oxford, UK: Elsevier; 2011. pp. 68–77.
  5. Vahdati M, Rasouli SA. Study of magnetic abrasive finishing on freeform surface. In: IMF, editor. Transactions of the IMF. 1st edition. Birmingham, UK: Taylor & Francis; 2016. pp. 294–302.
  6. Misra A, Pandey PM, Dixit US. Modeling of material removal in ultrasonic assisted magnetic abrasive finishing process. In: Elsevier, editor. International Journal of Mechanical Sciences. 1st edition. Oxford, UK: Elsevier; 2017. pp. 853–867.
  7. Ahmad S, Gangwar S, Yadav PC, Singh DK. Optimization of process parameters affecting surface roughness in magnetic abrasive finishing process. In: Taylor & Francis, editor. Materials and Manufacturing Processes. 1st edition. Philadelphia, USA: Taylor & Francis; 2017. pp. 1723–1729.
  8. Babbar A, Singh P, Farwaha HS. Regression model and optimization of magnetic abrasive finishing of flat brass plate. In: Indian Society for Education and Environment, editor. Indian Journal of Science and Technology. 1st edition. Chennai, India: ISEE; 2017. pp. 1–8.
  9. Mousa S, Al-kafaje J, Alwan A. Investigation of input parameters of MAF process on material removal using Al-1050 alloy plate work piece. In: AUISS, editor. Association of Arab Universities Journal of Engineering Sciences. 1st edition. Baghdad, Iraq: AUISS; 2018. pp. 277–288.
  10. Dhakar K, Rohilla V, Singla Y. Experimental evaluation of magnetic abrasive finishing process with diamond abrasive. In: Inderscience, editor. International Journal of Materials and Product Technology. 1st edition. Geneva, Switzerland: Inderscience; 2018. pp. 1–15.
  11. Guo J. A novel vibration-assisted magnetic abrasive polishing method for complex internal surface finishing. In: OSA, editor. Optics Express. 1st edition. Washington, DC, USA: OSA; 2018. pp. 1–12.
  12. Kadhum AH, Murad HH. Optimization of material removal rate and temperature in magnetic abrasive finishing process for stainless steel 304. In: University of Baghdad, editor. Al-Khwarizmi Engineering Journal. 1st edition. Baghdad, Iraq: University of Baghdad; 2019. pp. 22–29.
  13. Gao Y, Zhao Y, Zhang G, Yin F, Zhang H. Modeling of material removal in magnetic abrasive finishing process with spherical magnetic abrasive powder. In: Elsevier, editor. International Journal of Mechanical Sciences. 1st edition. Oxford, UK: Elsevier; 2020. pp. 1–14.
  14. Ahmadi F, Beiramlou H, Yazdi P. Effect of abrasive particle morphology along with other influencing parameters in magnetic abrasive finishing process. In: EDP Sciences, editor. Mechanics & Industry. 1st edition. Les Ulis, France: EDP Sciences; 2021. pp. 1–15.
  15. Xing B, Zou Y, Tojo M. Study on magnetic abrasive finishing combined with electrolytic process–precision surface finishing for SUS 304 stainless steel using pulse voltage. In: MDPI, editor. Journal of Manufacturing and Materials Processing. 1st edition. Basel, Switzerland: MDPI; 2022. pp. 1–14.
  16. Dixit N, Sharma V, Kumar P. Mathematical modeling of material removal and surface roughness in ultrasonic-assisted magnetic abrasive flow machining process. In: ASME, editor. Journal of Manufacturing Science and Engineering. 1st edition. New York, USA: ASME; 2022. pp. 121009-1–121009-12.
  17. Majeed M, Khadum AH, Al-Zubaidi S. Study of the effect of magnetic abrasive finishing on the material removal of AA1100 aluminium alloy. In: University of Baghdad, editor. Al-Khwarizmi Engineering Journal. 1st edition. Baghdad, Iraq: University of Baghdad; 2023. pp. 14–23.
  18. Singh V, Kumar H. Optimization of surface finishing and material removal of boron based HMMCs applying magnetic abrasive flow machining process. In: AIP, editor. AIP Conference Proceedings. 1st edition. Melville, USA: AIP Publishing; 2023. pp. 020084-1–020084-8.
  19. Wang L, Sun Y, Xiao Z, Yang F, Kang S, Liu Y, Zuo D. A review of magnetic abrasive finishing for the internal surfaces of metal additive manufactured parts. In: MDPI, editor. Journal of Manufacturing and Materials Processing. 1st edition. Basel, Switzerland: MDPI; 2024. pp. 1–25.
  20. Liu B, Ding Y, Yan Y, et al. Research on the prediction model of material removal rate in the magnetic abrasive finishing process. In: Springer, editor. The International Journal of Advanced Manufacturing Technology. 1st edition. London, UK: Springer; 2025. pp. 2181–2191.
Special Issue Subscription Original Research
Volume 14
Special Issue 01
Received 25/09/2025
Accepted 13/11/2025
Published 21/02/2026
Publication Time 149 Days
