Engineered Hybrid Nanoclay-Infused Nano-Polymers for Multifunctional Anti-Corrosive Coatings

Year : 2026 | Volume : 14 | Issue : 01 | Page : 40 53
    By

    V. Velmurugan,

  • Dhivakar Poosapadi,

  • K. P. S. Parmar,

  • S Arun Kumar,

  • S.Parameswari,

  • L Ranganathan,

  • Kirubakaran D,

  • Akash Deep Kushwaha,

  • S.Dhivya,

  1. Associate Professor, Department of Mechanical and Automation Engineering, Sri Sairam Engineering College, West Tambaram, Chennai, Tamil Nadu, India
  2. Lead Engineer, Quest Global North America, Windsor Connecticut, , United States
  3. Associate Professor, Department of Physics, Applied Science Cluster, UPES, Dehradun, Uttarakhand, India
  4. Assistant Professor, Department of Mechatronics Engineering, Kongu Engineering College, Erode, Tamil Nadu, India
  5. Associate Professor, Department of Chemistry, Velammal Institute of Technology, Panchetti, Tamil Nadu, India
  6. Professor, Department of Mechanical Engineering, Cambridge Institute of Technology, Ranchi, Jharkhand, India
  7. Professor, Department of Electrical and Electronics Engineering, St. Joseph’s Institute of Technology, Chennai, Tamil Nadu,
  8. Assistant Professor, Department of Mechanical Engineering, School of Engineering & I.T., MATS University, Arang, Chhattisgarh, India
  9. Professor, Department of Research and Innovation, Saveetha School of Engineering, SIMATS, Chennai, Tamil Nadu, India

Abstract

Polymer nanocomposites reinforced with layered nanofillers have emerged as an effective route to enhance structural stability in protective coating applications. Polymer–clay nanocomposites also provide a promising route to enhance mechanical robustness and environmental durability in coating systems. In this study, a hybrid epoxy–polyurethane (EPU) coating was reinforced using organo-modified montmorillonite (o-MMT) and layered double hydroxide intercalated with 2-mercaptobenzothiazole (LDH–MBT). Uniform dispersion and interfacial anchoring between the nanoclays and polymer chains were achieved using GPTMS, as confirmed by XRD and FTIR analyses. The incorporation of 1.0 wt% o-MMT and 0.7 wt% LDH–MBT resulted in a significant shift in coating performance. The water contact angle increased from 77° (neat EPU) to 95°, indicating reduced surface wettability and enhanced hydrophobicity. Water absorption over 30 days decreased from 2.8 wt% to 0.9 wt%, attributed to the tortuous diffusion pathway imposed by exfoliated silicate platelets and the chloride-trapping capability of LDH layers. Mechanical testing demonstrated improved surface hardness (HB → 2H) and reduced abrasion loss (35 mg → 24 mg) while retaining full flexibility and adhesion (5B). Electrochemical impedance spectroscopy showed an increase in |Z|₀.₀₁ Hz from ~1 × 10⁷ to >2 × 10⁸ Ω·cm², and potentiodynamic polarization revealed a reduction in corrosion current density from 2.3 µA·cm⁻² to 0.6 µA·cm⁻². These results confirm the synergistic reinforcement and active–passive protection mechanisms, establishing the hybrid nanocomposite coating as a durable, high-performance polymer-based protective material.

Keywords: Anti-corrosive, nanoclays, nanofillers, protective coatings, water absorption

[This article belongs to Journal of Polymer & Composites ]

How to cite this article:
V. Velmurugan, Dhivakar Poosapadi, K. P. S. Parmar, S Arun Kumar, S.Parameswari, L Ranganathan, Kirubakaran D, Akash Deep Kushwaha, S.Dhivya. Engineered Hybrid Nanoclay-Infused Nano-Polymers for Multifunctional Anti-Corrosive Coatings. Journal of Polymer & Composites. 2026; 14(01):40-53.
How to cite this URL:
V. Velmurugan, Dhivakar Poosapadi, K. P. S. Parmar, S Arun Kumar, S.Parameswari, L Ranganathan, Kirubakaran D, Akash Deep Kushwaha, S.Dhivya. Engineered Hybrid Nanoclay-Infused Nano-Polymers for Multifunctional Anti-Corrosive Coatings. Journal of Polymer & Composites. 2026; 14(01):40-53. Available from: https://journals.stmjournals.com/jopc/article=2026/view=236212


Browse Figures

References

  1. Palaniappan M, Palanisamy S, Mani T, et al. Physico-chemical characterization of Grewia monticola fibers for polymer composites. J Nat Fibers. 2022;19(17):15276–15290. doi:10.1080/15440478.2022.2123076.
  2. Chandramohan D, Sathish T, Dinesh Kumar S, Sudhakar M. Mechanical and thermal properties of jute/aloevera hybrid natural fiber reinforced composites. AIP Conf Proc. 2020;2283(1):020018.
  3. Palaniappan M, Palanisamy S, Mani T. Novel Ficus retusa aerial root fiber: a sustainable alternative for synthetic fibres in polymer composites reinforcement. Biomass Convers Biorefin. 2024;Ahead of print. doi:10.1007/s13399-024-05495-4.
  4. Vennila T, Surakasi R, Raghuram KS, Ravi G, Madhavarao S, Udagani C, Sudhakar M. Investigation on tensile behaviour of Al/Si₃N₄/sugarcane ash particles reinforced FSP composites. Int J Photoenergy. 2021;2021:1266–1270.
  5. Palaniappan M, Palanisamy S, Khan R, et al. Synthesis and suitability characterization of microcrystalline cellulose from Citrus × sinensis peel waste for polymer composite applications. J Polym Res. 2024;31(4):105. doi:10.1007/s10965-024-03946-0.
  6. Prabhu FF, Kumar KP, Shanmugam A, Kumar M, Senthil TS, Dhanraj JA. Study on wear behaviour of Al6061 MMC with nano-MoC. Mater Today Proc. 2022;69(Pt 3):1154–1158.
  7. Jasmin MN, Sathish S, Senthil TS, Naidu BA, Das AD, Arun KK, et al. Investigation on natural fiber reinforced polymer matrix composite. Mater Today Proc. 2023;74(Pt 1):60–63.
  8. Srinivas J, Karthikeyan KR, Senthil TS, Yesuraj K, Aultrin KSJ. Characterization of mechanical and viscoelastic properties of ceramic nanoparticle-reinforced polymer composites. J Polym Compos. 2024;13(1):71–82.
  9. Palanisamy S, Kalimuthu M, Palaniappan M, et al. Characterization of Acacia caesia bark fibers (ACBFs). J Nat Fibers. 2022;19(15):10241–10252. doi:10.1080/15440478.2021.1993493.
  10. Mary Jasmin N, Beena T, Senthil S, Sakthi S, Ramesh Kumar M, Rahul Alex S, et al. Machinability behaviors of synthesized beryllium composite. Mater Today Proc. 2023;74(Pt 1):40–43.
  11. Priya CB, Ravi Kumar V, Umamaheswari D, Venkatesh R, Karthigairajan M, Kaliappan S, et al. Bio-degradable waste banana and neem fiber reinforced epoxy hybrid composites: characteristics study. J Mech Sci Technol. 2024;38(4):1891–1896.
  12. Saravanan AK, Rajendra Prasad A, Muruganandam D, Saravanan G, Vivekanandan S, Sudhakar M. Study on natural fiber composites of jute, pineapple, and banana compositions percentage of weight basis for thermal resistance and thermal conductivity. Mater Today Proc. 2020;37:147–151.
  13. Logendran D, Gurusami K, AnandChakaravarthi MC, Puthilibai G, Suresh M, Sudhakar M. Experimental research on glass fibres/caustic soda treated banana fibers hybrid composite. Mater Today Proc. 2020;33:4408–4411.
  14. Muruganandam D, Jayapriya J, Suresh M, Chitradevi S, Puthilibai G, Sudhakar M. Simple study on behavior of composites with augmentation of silicon carbide on Al6061 aluminium alloy based on mechanical properties. Mater Today Proc. 2020;33:4573–4577.
  15. Palanisamy S, Kalimuthu M, Azeez A, et al. Wear properties and post-moisture absorption mechanical behavior of kenaf/banana-fiber-reinforced epoxy composites. 2022;10(4):32. doi:10.3390/fib10040032.
  16. Andrzejewski J, Szostak M, Barczewski M, Łuczak P. Cork-wood hybrid filler system for polypropylene and poly(lactic acid) based injection molded composites: structure evaluation and mechanical performance. Compos B Eng. 2019;163:655–668.
  17. Ahmad M, Rahmat AR, Hassan A. Mechanical properties of unplasticised PVC (PVC-U) containing rice husk and an impact modifier. Polym Compos. 2010;18(9):527–536.
  18. Palanisamy S, Mani T, Palaniappan M, Santulli C. Use of hemp waste for the development of mycelium-grown matrix biocomposites: a concise bibliographic review. 2023;18(4):8771–8780. doi:10.15376/biores.18.4.Palanisamy.
  19. Wu CS. Preparation, characterisation, and controlled-release of biodegradable polyester and marine-algae composite. J Polym Environ. 2015;23:356–366.
  20. Tomić MD, Dunjić B, Likić V, Bajat J, Rogan J, Djonlagić J. The use of nanoclay in preparation of epoxy anticorrosive coatings. Prog Org Coat. 2014;77(2):518–527.
  21. Padhu R, Shanmugavel R, Subramanian, et al. Evaluation of mechanical properties and Fick’s diffusion behaviour of aluminum-DMEM reinforced with hemp/bamboo/basalt woven fiber metal laminates under different stacking sequences. Ain Shams Eng J. 2024;102759. doi:10.1016/j.asej.2024.102759.
  22. Malin F, Znoj B, Šegedin U, Skale S, Golob J, Venturini P. Polyacryl–nanoclay composite for anticorrosion application. Prog Org Coat. 2013;76(10):1471–1476.
  23. Aruchamy K, Karuppusamy M, et al. Enhancement of mechanical properties of hybrid polymer composites using palmyra palm and coconut sheath fibers: the role of tamarind shell powder. 2024;20(1):698–724. doi:10.15376/biores.20.1.698-724.
  24. Yang MS, Huang J, Zhang H, Noël JJ, Hedberg YS, Chen J, et al. Study on the self-repairing effect of nanoclay in powder coatings for corrosion protection. 2023;13(7):1220.
  25. Bagherzadeh MR, Mahdavi F. Preparation of epoxy–clay nanocomposite and investigation on its anti-corrosive behavior in epoxy coating. Prog Org Coat. 2007;60(2):117–120.
  26. Kanat G, Yıldız E, Palanisamy S, Ashori A. Utilizing waste manhole covers and fibreboard as reinforcing fillers for thermoplastic composites. J Reinf Plast Compos. 2024;44(8):1108–1118. doi:10.1177/07316844241238507.
  27. Aly KI, Younis O, Mahross MH, Tsutsumi O, Mohamed MG, Sayed MM. Novel conducting polymeric nanocomposites embedded with nanoclay: synthesis, photoluminescence, and corrosion protection performance. Polym J. 2019;51(1):77–90.
  28. Danaee I, Darmiani E, Rashed GR, Zaarei D. Self-healing and anticorrosive properties of Ce(III)/Ce(IV) in nanoclay–epoxy coatings. Iran Polym J. 2014;23(11):891–898.
  29. Dhirde PG, Chada VG, Mallik BP, Moitra N. Alkyd–clay nanocomposites for improved anticorrosion and mechanical performance of coating. Polym Compos. 2018;39(8):2922–2931.
  30. Ramasubbu R, Kayambu A, Palanisamy S. Mechanical properties of epoxy composites reinforced with Areca catechu fibers containing silicon carbide. 2024;19(2):2353–2370. doi:10.15376/biores.19.2.2353-2370.
  31. Manasa S, Jyothirmayi A, Siva T, Sarada BV, Ramakrishna M, Sathiyanarayanan S, et al. Nanoclay-based self-healing corrosion protection coatings on aluminum A356.0 and AZ91 substrates. J Coat Technol Res. 2017;14(5):1195–1208.
Regular Issue Subscription Review Article
Volume 14
Issue 01
Received 04/11/2025
Accepted 13/11/2025
Published 03/01/2026
Publication Time 60 Days
