Polymer-Based Transparent Conductive Composites for Flexible Solar Panel Coatings

Year : 2025 | Volume : 13 | Issue : 03 | Page : 99 110
    By

    P. Suresh Kumar,

  • Krishnagandhi Pachiappan,

  • J Ananth,

  • M Pandikumar,

  • Arigela Sri Harsha,

  • Md Irshad Alam,

  • A.Vijayalakshmi,

  • Prashant Sunagar,

  • Sapthagirivasan V,

  1. Associate Professor, Department of Mechanical Engineering, R. V. R & J. C. College of Engineering, Guntur, Andhra Pradesh, India
  2. Assistant Professor, Department of Electrical and Electronics Engineering, Nandha Engineering College, Erode, Tamil Nadu, India
  3. Professor, Department of Marine Engineering, AMET University, Chennai, Tamil Nadu, India
  4. Associate Professor, Department of Electrical Power and Energy Conversion, Saveetha School of Engineering, Saveetha Institute of Medical and Technical Sciences (SIMATS), Chennai, Tamil Nadu, India
  5. Assistant Professor, Department of Mechanical Engineering, Koneru Lakshmaiah Education Foundation, Vaddeswaram, Tamil Nadu, India
  6. Assistant Professor, Department of Electrical Engineering, Sitamarhi Institute of Technology, Sitamarhi, Bihar, India
  7. Associate Professor, Department of Chemistry, R. M. K. Engineering College, Chennai, Tamil Nadu, India
  8. Associate Professor, Department of Civil Engineering, Sandip Institute of Technology and Research Centre, Maharashtra, India
  9. Department of mechanical Engineering, Arizona State University, United States

Abstract

This study investigates the fabrication and characterization of polymer-based transparent conductive composites (PTCCs) tailored for flexible solar panel coatings using poly(methyl methacrylate) (PMMA) and poly(ethylene terephthalate) (PET) matrices reinforced with silver nanowires (AgNWs), multi-walled carbon nanotubes (MWCNTs), and PEDOT:PSS. The composites were synthesized through a solution blending and doctor-blade casting method followed by post-treatments to enhance interfacial bonding and conductivity. Optical transmittance values above 85% were achieved across all composite types, with the highest recorded for pristine polymers (~92%) and PEDOT:PSS-based composites (~88%) even at 2 wt% filler loading. AgNW-reinforced composites showed good transparency (~86%) with significant electrical improvement, reducing sheet resistance from ~10⁶ Ω/sq (pure polymer) to ~100 Ω/sq at just 0.5 wt% filler concentration. PEDOT:PSS composites further achieved ~300 Ω/sq after ethylene glycol doping and thermal annealing. MWCNT-filled systems offered enhanced thermal performance, increasing the decomposition onset temperature by 20–25 °C, while AgNWs and PEDOT:PSS composites showed moderate thermal gains of ~10–15 °C. Mechanical testing revealed up to a 15% increase in tensile strength and stable flexibility across all systems, with PEDOT:PSS composites maintaining integrity after over 1000 bending cycles. These results confirm that PTCCs optimized with low filler concentrations can simultaneously offer high optical clarity, superior electrical conductivity, and robust thermal and mechanical stability—making them promising alternatives to conventional ITO coatings for next-generation flexible optoelectronic and photovoltaic applications.

Keywords: Flexible solar panels, silver nanowires (AgNWs), PEDOT:PSS, Multi-walled carbon nanotubes (MWCNTs), Transparent conductive composites.

[This article belongs to Journal of Polymer and Composites ]

aWQ6MjEwNjkwfGZpbGVuYW1lOmVmZjc2YzYzLWZpLndlYnB8c2l6ZTp0aHVtYm5haWw=
How to cite this article:
P. Suresh Kumar, Krishnagandhi Pachiappan, J Ananth, M Pandikumar, Arigela Sri Harsha, Md Irshad Alam, A.Vijayalakshmi, Prashant Sunagar, Sapthagirivasan V. Polymer-Based Transparent Conductive Composites for Flexible Solar Panel Coatings. Journal of Polymer and Composites. 2025; 13(03):99-110.
How to cite this URL:
P. Suresh Kumar, Krishnagandhi Pachiappan, J Ananth, M Pandikumar, Arigela Sri Harsha, Md Irshad Alam, A.Vijayalakshmi, Prashant Sunagar, Sapthagirivasan V. Polymer-Based Transparent Conductive Composites for Flexible Solar Panel Coatings. Journal of Polymer and Composites. 2025; 13(03):99-110. Available from: https://journals.stmjournals.com/jopc/article=2025/view=210694


Browse Figures

References

  1. Kim Y, Zhu J, Yeom B, Di Prima M, Su X, Kim J-G, et al. Stretchable nanoparticle conductors with self-organized conductive pathways. Nature. 2013;500(7460):59–63.
  2. Zhang J, Zhao S, Zhu R, Sun X, Wang J, Li X, et al. Recent progress on flexible inorganic single-crystalline semiconductor thin-film materials and devices. Adv Mater. 2020;32(45):e1903266.
  3. Yu Z, Li L, Zhang Q, Hu W, Pei Q. Silver nanowire–polymer composite electrodes for efficient polymer solar cells. Adv Mater. 2011;23(38):4453–7.
  4. Liu C, Yu D, Zhang Y, Li J, Wang S, Jiang C, et al. Recent advances in transparent conductive films based on silver nanowires: design, fabrication, and applications. Adv Electron Mater. 2018;4(7):1700471.
  5. Heo Y, Kim D, Kim J, Kim H, Kim J, Kim Y, et al. Highly flexible transparent conducting electrodes using graphene/metal nanowire hybrid structure. ACS Appl Mater Interfaces. 2013;5(11):5115–9.
  6. Li YQ, Yu T, Yang T, Zheng L, Liao K. Bio-inspired nacre-like composite films based on graphene with superior mechanical, electrical, and biocompatible properties. Adv Mater. 2012;24(25):3426–31.
  7. Cai G, Darmawan P, Cui M, Wang J, Chen J, Magdassi S, et al. Highly stable transparent conductive silver grid/PEDOT:PSS electrodes for integrated bifunctional flexible electrochromic supercapacitors. Adv Energy Mater. 2016;6(21):1600680.
  8. Park J, Kim J, Hong J, Kim S, Lee H, Lee J, et al. Flexible and transparent graphene-based supercapacitor. Sci Rep. 2012;2:501.
  9. Shi H, Liu C, Jiang Q, Xu J. Effective approaches to improve the electrical conductivity of PEDOT:PSS: a review. Adv Electron Mater. 2015;1(4):1500017.
  10. Mengistie DA, Ibrahem MA, Wang P-C, Chu C-W. Highly conductive PEDOT:PSS treated with formic acid for ITO-free polymer solar cells. ACS Appl Mater Interfaces. 2014;6(4):2292–9.
  11. Cheng X, Wang R, Sun X, Gao J, Tang L, Zhang L, et al. Enhancing the conductivity and thermoelectric property of PEDOT:PSS films by ethylene glycol post-treatment. Synth Met. 2015;209:169–75.
  12. Song Y, Wang N, Zhang L, Wei W, Fan Z, Wang Y, et al. Highly flexible and transparent graphene-based wearable electrochemical glucose sensor. Biosens Bioelectron. 2018;110:168–74.
  13. Wang X, Zhi L, Mullen K. Transparent, conductive graphene electrodes for dye-sensitized solar cells. Nano Lett. 2008;8(1):323–7.
  14. Xu Y, Bai H, Lu G, Li C, Shi G. Flexible graphene films via the filtration of water-soluble noncovalent functionalized graphene sheets. J Am Chem Soc. 2008;130(18):5856–7.
  15. Lee J-Y, Connor ST, Cui Y, Peumans P. Solution-processed metal nanowire mesh transparent electrodes. Nano Lett. 2008;8(2):689–92.
  16. Jin S, Kim S, Lee J, Lee D, Lee H, Lee J, et al. Highly conductive and stretchable Ag nanowire/Ag nanoparticle composite conductors for flexible and wearable electronics. ACS Appl Mater Interfaces. 2017;9(25):21298–306.
  17. Choi K, Nam S, Lee Y, Lee D, Kim J, Kang J, et al. Synergistic improvement of transparent conducting electrodes by combining graphene and silver nanowire networks. Adv Funct Mater. 2015;25(5):689–95.
  18. Gupta R, Choudhary K, Sharma A, Singh R, Kumar P, Dutta S, et al. Recent advances in flexible and stretchable bio-electrochemical sensors for healthcare applications. Biosens Bioelectron. 2021;180:113122.
  19. Xu J, Wang S, Wang G, Wang Y. Enhanced mechanical and electrical properties of graphene oxide/PMMA composites via surface modification and in situ polymerization. Compos Part A Appl Sci Manuf. 2019;124:105473.
  20. Karthik A, Bhuvaneshwaran M, Senthil Kumar MS, Palanisamy S, Palaniappan M, Ayrilmis N. A review on surface modification of plant fibers for enhancing properties of biocomposites. Chem Select. 2024;9(22):e202400650. doi:10.1002/slct.202400650.
  21. Palaniappan, M., Palanisamy, S., Khan, R. et al. Synthesis and suitability characterization of microcrystalline cellulose from Citrus x sinensis sweet orange peel fruit waste-based biomass for polymer composite applications. J Polym Res 31, 105 (2024). https://doi.org/10.1007/s10965-024-03946-0.
  22. Murugesan TM, Palanisamy S, Santulli C, Palaniappan M. Mechanical characterization of alkali treated Sansevieria cylindrica fibers–Natural rubber composites. Mater Today Proc. 2022;62(Pt 8):5402–6. doi:10.1016/j.matpr.2022.03.609.
  23. Palanisamy, S.; Mayandi, K.; Palaniappan, M.; Alavudeen, A.; Rajini, N.; Vannucchi de Camargo, F.; Santulli, C. Mechanical Properties of Phormium Tenax Reinforced Natural Rubber Composites. Fibers 2021, 9, 11. https://doi.org/10.3390/fib9020011.
  24. Palanisamy, S.; Kalimuthu, M.; Santulli, C.; Palaniappan, M.; Nagarajan, R.; Fragassa, C. Tailoring Epoxy Composites with Acacia caesia Bark Fibers: Evaluating the Effects of Fiber Amount and Length on Material Characteristics. Fibers 2023, 11, 63. https://doi.org/10.3390/fib11070063.
  25. Keerthiveettil Ramakrishnan, Sumesh & Palanisamy, Sivasubramanian & Khan, Tabrej & Ajithram, A. & Ahmed, Omar. (2024). Mechanical, morphological and wear resistance of natural fiber / glass fiber-based polymer composites. BioResources. 19. 3271-3289. 10.15376/biores.19.2.3271-3289.
  26. Sekhar KC, Arunchander A, Das S, Katiyar RS. Conductivity enhancement in PEDOT:PSS films through secondary doping with ionic liquids. Org Electron. 2014;15(5):1027–35.
  27. Ganeshkumar, S.; Kumar, S.D.; Magarajan, U.; Rajkumar, S.; Arulmurugan, B.; Sharma, S.; Li, C.; Ilyas, R.A.; Badran, M.F. Investigation of Tensile Properties of Different Infill Pattern Structures of 3D-Printed PLA Polymers: Analysis and Validation Using Finite Element Analysis in ANSYS. Materials 2022, 15, 5142.
  28. Albaqami MD, Dwivedi YD, Krishnamoorthy N, Kumar ML, Manjunatha LH, Chowdary ChM, et al. Investigation on mechanical and thermal properties of a KENAF/JUTE Fiber-Reinforced polyester hybrid biocomposite. Advances in Polymer Technology. 2022 Jul 13;2022:1–6.
