ANN Approach to Forecasting the Strength of Nano Silica Incorporated Geopolymer Composite

Year : 2025 | Volume : 13 | Special Issue 03 | Page : 267 278
    By

    Sagar Paruthi,

  • Ibadur Rahman,

  • Asif Husain,

  1. Assistant Professor, School of Architecture & Design, K. R. Mangalam University, Gurugram, Haryana, India
  2. Assistant Professor, Department of Civil Engineering, Jamia Millia Islamia, New Delhi, India
  3. Professor, Department of Civil Engineering, Jamia Millia Islamia, New Delhi, India

Abstract

Coal and steel industry by-products, such as fly ash (FA) and blast furnace slag (GGBS), have gained significant attention as precursors for geopolymer concrete (GPC) due to their high aluminosilicate content, offering a sustainable alternative to conventional cement. Nano silica (NS), recognized for its exceptional pozzolanic activity and ability to refine microstructure, has shown potential to enhance the mechanical and durability properties of GPC. This study investigates the influence of NS incorporation at varying percentages (1%, 1.5%, 2%) in GPC, cured at different temperatures (27 0C, 60 0C, 90 0C, 120 0C), on compressive strength (CS), split tensile strength (STS) and flexural strength (FS). Experimental results reveal that GPC cured at 90 0C for 28 days exhibits the highest strengths i.e. CS of 55.96 MPa, STS of 5.63 MPa, and FS pf 5.66 MPa, demonstrating the effectiveness of heat curing in optimizing mechanical properties. However, the experimental determination of GPC properties is resource intensive. This research introduces machine learning, especially artificial neural networks (ANN), as a predictive tool. The ANN models, trained on 20 GPC mix designs, accurately predict CS (R2 = 0.9797), STS (R2 = 0.9847), and FS (R2 = 0.9864), highlighting their reliability. Compared to traditional modeling approaches, ANN offers superior prediction accuracy, aiding in efficient material proportioning and optimization. The novelty of this research lies in combining advanced nanotechnology and machine learning to address the dual challenges of sustainability and performance in GPC, bridging experimental and computational domains for future infrastructure applications.

Keywords: ANN, nano silica, geopolymer concrete, heat cured, compressive strength.

[This article belongs to Special Issue under section in Journal of Polymer and Composites (jopc)]

aWQ6MjEwMjI0fGZpbGVuYW1lOjY1NzdmYjc0LWZpLndlYnB8c2l6ZTp0aHVtYm5haWw=
How to cite this article:
Sagar Paruthi, Ibadur Rahman, Asif Husain. ANN Approach to Forecasting the Strength of Nano Silica Incorporated Geopolymer Composite. Journal of Polymer and Composites. 2025; 13(03):267-278.
How to cite this URL:
Sagar Paruthi, Ibadur Rahman, Asif Husain. ANN Approach to Forecasting the Strength of Nano Silica Incorporated Geopolymer Composite. Journal of Polymer and Composites. 2025; 13(03):267-278. Available from: https://journals.stmjournals.com/jopc/article=2025/view=210231


Browse Figures

References

1. Davidovits J, Cordi S. Synthesis of new high temperature geo-polymers for reinforced plastics/composites. Spe Pactec. 1979;79:151-4.

2. Garg R, Garg R, Eddy NO, Khan MA, Khan AH, Alomayri T, et al. Mechanical strength and durability analysis of mortars prepared with fly ash and nano-metakaolin. Case Studies in Construction Materials. 2023;18:e01796.

3. Ma C-K, Awang AZ, Omar W. Structural and material performance of geopolymer concrete: A review. Construction and Building Materials. 2018;186:90-102.

4. Shahmansouri AA, Bengar HA, Ghanbari S. Compressive strength prediction of eco-efficient GGBS-based geopolymer concrete using GEP method. Journal of Building Engineering. 2020;31:101326.

5. Nazari A, Bagheri A, Riahi S. Properties of geopolymer with seeded fly ash and rice husk bark ash. Materials Science and Engineering: A. 2011;528(24):7395-401.

6. Alraddadi S, Assaedi H. Characterization and potential applications of different powder volcanic ash. Journal of King Saud University-Science. 2020;32(7):2969-75.

7. Palomo A, Grutzeck M, Blanco M. Alkali-activated fly ashes: A cement for the future. Cement and concrete research. 1999;29(8):1323-9.

8. Alekhya P, Aravindan S. Experimental investigations on geopolymer concrete. Int J Civ Eng Technol (IJCIET). 2014;5(4):01-9.

9. Paruthi S, Husain A, Alam P, Khan AH, Hasan MA, Magbool HM. A review on material mix proportion and strength influence parameters of geopolymer concrete: Application of ANN model for GPC strength prediction. Construction and Building Materials. 2022;356:129253.

10. Paruthi S, Rahman I, Husain A, Hasan MA, Khan AH. Effects of chemicals exposure on the durability of geopolymer concrete incorporated with silica fumes and nano-sized silica at varying curing temperatures. Materials. 2023;16(18):6332.

11. Paruthi S, Rahman I, Husain A, Khan AH, Manea-Saghin A-M, Sabi E. A comprehensive review of nano materials in geopolymer concrete: Impact on properties and performance. Developments in the Built Environment. 2023;16:100287.

12. Paruthi S, Rahman I, Khan AH, Sharma N, Alyaseen A. Strength, durability, and economic analysis of GGBS-based geopolymer concrete with silica fume under harsh conditions. Scientific Reports. 2024;14(1):31572.

13. Nagajothi S, Elavenil S. Influence of aluminosilicate for the prediction of mechanical properties of geopolymer concrete–artificial neural network. Silicon. 2020;12(5):1011-21.

14. Piro NS, Mohammed AS, Hamad SM. Evaluate and predict the resist electric current and compressive strength of concrete modified with GGBS and steelmaking slag using mathematical models. Journal of Sustainable Metallurgy. 2023;9(1):194-215.

15. Kong DL, Sanjayan JG. Damage behavior of geopolymer composites exposed to elevated temperatures. Cement and Concrete Composites. 2008;30(10):986-91.

16. Davidovits J. Synthetic mineral polymer compound of the silicoaluminates family and preparation process. Google Patents; 1984.

17. Reddy MS, Dinakar P, Rao BH. Mix design development of fly ash and ground granulated blast furnace slag based geopolymer concrete. Journal of Building Engineering. 2018;20:712-22.

18. Paruthi S, Khan AH, Isleem HF, Alyaseen A, Mohammed AS. Influence of silica fume and alccofine on the mechanical performance of GGBS-based geopolymer concrete under varying curing temperatures. Journal of Structural Integrity and Maintenance. 2025;10(1):2447661.

19. Huynh AT, Nguyen QD, Xuan QL, Magee B, Chung T, Tran KT, et al. A machine learning-assisted numerical predictor for compressive strength of geopolymer concrete based on experimental data and sensitivity analysis. Applied Sciences. 2020;10(21):7726.

20. Kaliraman B, Verma R, Paruthi S. Internet of things in sustainable concrete production.  Recent Developments and Innovations in the Sustainable Production of Concrete: Elsevier; 2025. p. 621-33.

21. Verma R, Kaliraman B, Paruthi S. Machine learning in concrete construction: applications, challenges, and future aspects.  Recent Developments and Innovations in the Sustainable Production of Concrete: Elsevier; 2025. p. 577-93.

22. Lin Y, Lai C-P, Yen T. Prediction of ultrasonic pulse velocity (UPV) in concrete. Materials Journal. 2003;100(1):21-8.

23. Dao DV, Ly H-B, Trinh SH, Le T-T, Pham BT. Artificial intelligence approaches for prediction of compressive strength of geopolymer concrete. Materials. 2019;12(6):983.

24. Dao DV, Trinh SH, Ly H-B, Pham BT. Prediction of compressive strength of geopolymer concrete using entirely steel slag aggregates: Novel hybrid artificial intelligence approaches. Applied Sciences. 2019;9(6):1113.

25. Nguyen KT, Nguyen QD, Le TA, Shin J, Lee K. Analyzing the compressive strength of green fly ash based geopolymer concrete using experiment and machine learning approaches. Construction and Building Materials. 2020;247:118581.

26. Ling Y, Wang K, Wang X, Li W. Prediction of engineering properties of fly ash-based geopolymer using artificial neural networks. Neural Computing and Applications. 2021;33(1):85-105.

27. Kheder G. A two stage procedure for assessment of in situ concrete strength using combined non-destructive testing. Materials and Structures. 1999;32(6):410-7.

28. Trtnik G, Kavčič F, Turk G. Prediction of concrete strength using ultrasonic pulse velocity and artificial neural networks. Ultrasonics. 2009;49(1):53-60.

29. Ahmad M, Rashid K, Tariq Z, Ju M. Utilization of a novel artificial intelligence technique (ANFIS) to predict the compressive strength of fly ash-based geopolymer. Construction and Building Materials. 2021;301:124251.

30. Yadollahi MM, Benli A, Demirboga R. Application of adaptive neuro-fuzzy technique and regression models to predict the compressive strength of geopolymer composites. Neural Computing and Applications. 2017;28:1453-61.

31. Garg A, Aggarwal P, Aggarwal Y, Belarbi M, Chalak H, Tounsi A, et al. Machine learning models for predicting the compressive strength of concrete containing nano silica. Computers and Concrete. 2022;30(1):33.

32. Paruthi S, Rahman I, Husain A. Utilizing ANFIS for strength characteristics forecasting in variable heat-cured geopolymer composites. Materials Today: Proceedings. 2024.

33. Paruthi S, Rahman I, Husain A. Comparative studies of different machine learning algorithms in predicting the compressive strength of geopolymer concrete. Computers and Concrete. 2023;32(6):607.

34. Kumari P, Paruthi S, Alyaseen A, Khan AH, Jijja A. Predictive performance assessment of recycled coarse aggregate concrete using artificial intelligence: A review. Cleaner Materials. 2024:100263.

35. Elshafey AA, Dawood N, Marzouk H, Haddara M. Crack width in concrete using artificial neural networks. Engineering structures. 2013;52:676-86.

36. Jiang G, Keller J, Bond PL, Yuan Z. Predicting concrete corrosion of sewers using artificial neural network. Water research. 2016;92:52-60.

37. Emad W, Mohammed AS, Bras A, Asteris PG, Kurda R, Muhammed Z, et al. Metamodel techniques to estimate the compressive strength of UHPFRC using various mix proportions and a high range of curing temperatures. Construction and Building Materials. 2022;349:128737.

38. Kong X, Khambadkone AM. Modeling of a PEM fuel-cell stack for dynamic and steady-state operation using ANN-based submodels. IEEE Transactions on Industrial Electronics. 2009;56(12):4903-14.

39. Anderson JA. Cognitive and psychological computation with neural models. IEEE transactions on systems, man, and cybernetics. 1983(5):799-815.

40. Golafshani EM, Behnood A, Arashpour M. Predicting the compressive strength of normal and High-Performance Concretes using ANN and ANFIS hybridized with Grey Wolf Optimizer. Construction and Building Materials. 2020;232:117266.

41. Azadeh A, Seif J, Sheikhalishahi M, Yazdani M. An integrated support vector regression–imperialist competitive algorithm for reliability estimation of a shearing machine. International Journal of Computer Integrated Manufacturing. 2016;29(1):16- 24.

42. Paruthi S, Khan AH, Kumar A, Kumar F, Hasan MA, Magbool HM, et al. Sustainable cement replacement using waste eggshells: A review on mechanical properties of eggshell concrete and strength prediction using artificial neural network. Case Studies in Construction Materials. 2023;18:e02160.
