Fabrication and Characterization of Almond Skin Powder Reinforced PLA Based Composite Filaments for Fused Filament Fabrication

Year : 2025 | Volume : 13 | Special Issue 02 | Page : 530-539
    By

    Ravi Kumar,

  • Kapil Chawla,

  • Jaspreet Singh,

  1. Assistant Professor, School of Mechanical Engineering, Lovely Professional University, Phagwara, Punjab, India
  2. Associate Professor, School of Mechanical Engineering, Lovely Professional University, Phagwara, Punjab, India
  3. Professor, School of Mechanical Engineering, Lovely Professional University, Phagwara, Punjab, India

Abstract

Researchers around the globe are increasingly utilizing recycling methods to address waste generated from polymers, spurred by the dire need to deal with environmental challenges promoting sustainable practices. Polymers are having highly-stable long-chain polymer structure which makes it difficult to degrade easily posing many environmental and health challenges, hence, recycling of the polymers is the sole method to mitigate harmful effects. However, there has been relatively little focus on producing fused filaments using secondary recycled Polylactic acid (2° PLA) reinforced with industrial waste of almond skin. The goal of this study is to fabricate fused filaments for fused filament fabrication (FFF) in additive manufacturing. The process involves controlling parameters such as torque (0.1 Nm, 0.2 Nm, 0.3 Nm), load (7.5 kg, 10 kg, 12.5 kg), temperature (175°C, 185°C, 195°C) of a twin-screw extruder using 2° PLA reinforced with almond skin. Taguchi’s orthogonal array has been applied to prepare composite filaments. Total 9-composite filaments have been prepared with a composition of 94% 2° PLA and 6% almond skin by %wt. The highest peak strength  (43.85 MPa) of the 2° PLA + almond skin composite filament was achieved at 0.1 Nm torque, 12.5 kg load and 195°C extrusion temperature. The morphological and thermal characteristics of the fused filaments were examined through scanning electron microscopy and differential scanning calorimetry. Further, porosity analysis indicates that lower porosity percentages in the filaments lead to improved mechanical properties.

Keywords: Polylactic acid, almond skin, twin screw extruder (TSE), scanning electron microscopy (SEM), differential scanning calorimetry (DSC)

[This article belongs to Special Issue under section in Journal of Polymer and Composites (jopc)]

aWQ6MjA4MTQ5fGZpbGVuYW1lOmE1NDQzYWQ1LWZpLXBuZy53ZWJwfHNpemU6dGh1bWJuYWls
How to cite this article:
Ravi Kumar, Kapil Chawla, Jaspreet Singh. Fabrication and Characterization of Almond Skin Powder Reinforced PLA Based Composite Filaments for Fused Filament Fabrication. Journal of Polymer and Composites. 2025; 13(02):530-539.
How to cite this URL:
Ravi Kumar, Kapil Chawla, Jaspreet Singh. Fabrication and Characterization of Almond Skin Powder Reinforced PLA Based Composite Filaments for Fused Filament Fabrication. Journal of Polymer and Composites. 2025; 13(02):530-539. Available from: https://journals.stmjournals.com/jopc/article=2025/view=208157


Browse Figures

References

  1. Chawla K, Singh J, Singh R. On recyclability of thermosetting polymer and wood dust as reinforcement in secondary recycled ABS for nonstructural engineering applications. Journal of Thermoplastic Composite Materials. 2022 Jul;35(7):913-37.
  2. Shent H, Pugh RJ, Forssberg E. A review of plastics waste recycling and the flotation of plastics. Resources, Conservation and Recycling. 1999 Feb 1;25(2):85-109.
  3. Chawla K, Singh R, Singh J. Segregation and recycling of plastic solid waste: a review. Advances in Materials Science and Engineering: Select Proceedings of ICFMMP 2020:205-21.
  4. Kumar S, Panda AK, Singh RK. A review on tertiary recycling of high-density polyethylene to fuel. Resources, Conservation and Recycling. 2011 Sep 1;55(11):893-910.
  5. Singh J, Singh R, Singh H, Verma AK. Investigations for mechanical properties and biocompatibility of SS-316L implant prepared as rapid investment casting for batch production. Sādhanā. 2018 May;43:1-0.
  6. K. Chua, M. Matham and Y. Kim. Lasers in 3D Printing and Manufacturing. World Scientific Series in 3D Printing: Volume 2
  7. Singh N, Singh R, Ahuja IP. Thermomechanical investigations of SiC and Al2O3–reinforced HDPE. Journal of Thermoplastic Composite Materials. 2019 Oct;32(10):1347-60.
  8. Ranjan N, Singh R, Ahuja IP. Development of PLA-HAp-CS-based biocompatible functional prototype: a case study. Journal of Thermoplastic Composite Materials. 2020 Mar;33(3):305-23.
  9. Zhang Z, Cao B, Jiang N. The mechanical properties and degradation behavior of 3D-printed cellulose nanofiber/polylactic acid composites. Materials. 2023 Sep 13;16(18):6197.
  10. Santos NV, Cardoso DC. 3D printing of vegetable yarn-reinforced polymer components. Journal of Cleaner Production. 2023 Aug 20;415:137870.
  11. Cao M, Cui T, Yue Y, Li C, Guo X, Jia X, Wang B. Investigation of carbon fiber on the tensile property of FDM-produced PLA specimen. Polymers. 2022 Dec 1;14(23):5230.
  12. Zhao G, Liu HY, Cui X, Du X, Zhou H, Mai YW, Jia YY, Yan W. Tensile properties of 3D-printed CNT-SGF reinforced PLA composites. Composites Science and Technology. 2022 Nov 10;230:109333.
  13. Chen J, Teng Z, Wu J. Recycling of waste FRP and corn straw in wood plastic composite. Polymer Composites. 2017 Oct;38(10):2140-5.
  14. Ryder MA, Lados DA, Iannacchione GS, Peterson AM. Fabrication and properties of novel polymer-metal composites using fused deposition modeling. Composites Science and Technology. 2018 Apr 12;158:43-50.
  15. Makannavar R, Keshavamurthy R, Biradar M. Mechanical Properties of Graphite Filled ABS Parts Developed by Fused Deposition Modelling. In IOP Conference Series: Materials Science and Engineering; 2019 Nov 1 (Vol. 577, No. 1, p. 012146). IOP Publishing.
  16. Kumar S, Ramesh MR, Doddamani M, Rangappa SM, Siengchin S. Mechanical characterization of 3D printed MWCNTs/HDPE nanocomposites. Polymer Testing. 2022 Oct 1;114:107703.
  17. Tambrallimath V, Keshavamurthy R, Saravanabavan D, Koppad PG, Kumar GP. Thermal behavior of PC-ABS based graphene filled polymer nanocomposite synthesized by FDM process. Composites Communications. 2019 Oct 1;15:129-34.
  18. Kartal F, Kaptan A. Sustainable Reinforcement of PLA Composites with Waste Beech Sawdust for Enhanced 3D-Printing Performance. Journal of Materials Engineering and Performance. 2024 Nov 5:1-2.
  19. Rodriguez-Pacheco LC, Lardizabal-Gutierrez D, Pantoja-Espinoza JC, de la Torre-Saenz L, Estrada-Moreno IA, Paraguay-Delgado F. Novel 3D printing filaments: PLA and zinc carbonate basic composites for laser-assisted thermal decomposition. Journal of Materials Research and Technology. 2024 Jul 1;31:2266-78.
  20. Wang A, Tang X, Zeng Y, Zou L, Bai F, Chen C. Carbon fiber-reinforced PLA composite for fused deposition modeling 3D printing. Polymers. 2024 Jul 26;16(15):2135.
  21. Shunmugam MN, Sankaranarayanan S, Pandiarajan N, Parrthipan BK, Pandiarajan B. Enhancing Mechanical Properties of PLA Filaments through Orange Peel Powder Reinforcement: Optimization of 3D Printing Parameters. Applied Science and Engineering Progress. 2024 Oct 17;17(4):7536-.
  22. Kalimuthu M, Sethu S, Vijay RD, Surya KS, Karthikeyan KR, Sethuramalingam P. Production and characterization of biodegradable polylactic acid composites 3D filament from agro waste. Interactions. 2024 Aug 19;245(1):225.
  23. Singh Boparai K, Singh R, Singh H. Experimental investigations for development of Nylon6-Al-Al2O3 alternative FDM filament. Rapid Prototyping Journal. 2016 Mar 21;22(2):217-24.
