E-glass Fiber Epoxy Composites: Role of Al2O3/SiC Fillers in Physical, Flammability and Mechanical Characteristics


Year : 2025 | Volume : 13 | Issue : 01 | Page : 238-250
    By

    Manoj Sharma,

  1. Associate Professor, Department of Mechanical Engineering, Poornima College of Engineering, Jaipur, Rajasthan, India

Abstract

This study investigates the effects of varying weight percentages of Silicon Carbide and Alumina particles in epoxy-based composites, fabricated through compression molding, on their physical and mechanical properties. Comparing different studies on carbon fiber-reinforced polymer (CFRP) composites, as well as glass fiber-reinforced polymer (GFRP) composites, especially with the reinforcement of nanoparticles such as silicon carbide (SiC), alumina (Al2O3) and graphene. The investigations cover fabrication methods, like vacuum infusion and compression molding and their impact on tensile, flexural, hardness, and impact properties, highlighting the effects of varying filler types, particle sizes, and weight percentages. To understand the characteristics of ceramic-reinforced hybrid composites in accordance with ASTM standards, the research evaluates the density, moisture content, dimensional stability, tensile strength, flexural strength, impact resistance and hardness of the ceramic-reinforced hybrid composites in accordance with ASTM standards. Fractographic analysis of tensile and flexural specimens was conducted using SEM. The study highlights a reduction in composite density and examines how immersion time in water and the varying ceramic content influence dimensional stability. The composites exhibited optimal tensile strength (172.36±8.028 MPa), flexural strength (164.493±9.918 MPa), impact resistance (24.2±1.643 J/m) and hardness (77.3±1.702 HSN) at 4 wt% SiC/Al2O3, and thus turned out to be highly promising for applications in automotive parts and sports tools.

Keywords: About Glass Fiber, Epoxy resin, SiC, Al2O3, Compression molding, Flammability.

[This article belongs to Journal of Polymer and Composites ]

How to cite this article:
Manoj Sharma. E-glass Fiber Epoxy Composites: Role of Al2O3/SiC Fillers in Physical, Flammability and Mechanical Characteristics. Journal of Polymer and Composites. 2025; 13(01):238-250.
How to cite this URL:
Manoj Sharma. E-glass Fiber Epoxy Composites: Role of Al2O3/SiC Fillers in Physical, Flammability and Mechanical Characteristics. Journal of Polymer and Composites. 2025; 13(01):238-250. Available from: https://journals.stmjournals.com/jopc/article=2025/view=197253


Browse Figures

References

  1. Ertan Kosedag, Recep Ekici, Yildiz N, Umut Caliskan. Effect of SiC and graphene nanoparticles on the mechanical properties of carbon fiber‐reinforced epoxy composites. Polymer Composites. 2023 Sep 4;44(12):8578–88.
  2. Shahabaz SM, Mehrotra P, Kalita H, Sharma S, Naik N, Noronha DJ, et al. Effect of Al2O3 and SiC Nano-Fillers on the Mechanical Properties of Carbon Fiber-Reinforced Epoxy Hybrid Composites. Journal of Composites Science [Internet]. 2023 Apr 1 [cited 2023 Apr 7];7(4):133. Available from: https://www.mdpi.com/2504-477X/7/4/133#:~:text=%25%20of%20nano%2DAl2O
  3. Sathish S, Kumaresan K, Prabhu L, Gokulkumar S, Karthi N, Vigneshkumar N. Experimental investigation of mechanical and morphological properties of flax fiber reinforced epoxy composites incorporating SiC and Al2O3. Materials Today: Proceedings. 2019 Oct;
  4. Kwiecień, J. Majta, Dziedzic D. Shear deformation and failure of explosive welded Inconel-microalloyed steels bimetals. Archives of Civil and Mechanical Engineering. 2014 Jan 1;14(1):
    32–9.
  5. Sharma M, Narayan Lal Jain, Purohit JK. Analysis of circular economy barriers in manufacturing context for indian industries: a BWM ranking process. Environment, Development and Sustainability. 2023 Oct 4;
  6. Study of Stress Corrosion Cracking of Alloy 600 in High Temperature High Pressure water - ProQuest [Internet]. Proquest.com. 2024. Available from: https://www.proquest.com/openview/be834adb1b62dba9976e4116f3743763/1?pq-origsite=gscholar&cbl=51922
  7. Kiran MD, Govindaraju HK, Jayaraju T. Evaluation of Mechanical Properties of Glass Fiber Reinforced Epoxy Polymer Composites with Alumina, Titanium dioxide and Silicon Carbide Fillers. Materials Today: Proceedings. 2018;5(10):22355–61.
  8. Singh N, Singh R, Singh R. Thermomechanical investigations of SiC and Al2O3–reinforced HDPE. 2019 Oct 1;32(10):1347–60.
  9. Sharma M, Narayan Lal Jain, Purohit JK. Analysis of Circular Economy Enablers in Manufacturing Context for Indian Industries: A ELECTRE method Ranking Process. Evergreen. 2023 Sep 1;10(3):1156–68.
  10. Sanya OT, Oji B, Owoeye SS, Egbochie EJ. Influence of particle size and particle loading on mechanical properties of silicon carbide–reinforced epoxy composites. The International Journal of Advanced Manufacturing Technology. 2019 Jun 26;103(9-12):4787–94.
  11. Sharma R, Kumar Gupta P. Synthesis and chemical resistance of aluminum oxide and silicon carbide (1:1) filled Bi-Directional woven E- glass fiber reinforcement epoxy polymer composites. Materials Today: Proceedings. 2022 Apr;
  12. Sharma R, Sharma D. Synthesis and experimental investigation of physical behavior of coconut shell particular and walnut shell particular filled epoxy polymer composites. Materials Today: Proceedings. 2023 Mar;
  13. Luo H, Su H, Dong C, Li Y. Passivation and electrochemical behavior of 316L stainless steel in chlorinated simulated concrete pore solution. Applied Surface Science. 2017 Apr 1;400:38–48.
  14. Sharma M, Chaudhary R, Nair R. Enablers Impacting the Circular Economy in Indian Manufacturing Industries: Modeling through a SmartPLS4-SEM Approach. Journal of the Institution of Engineers (India) Series C (IEIC). 2024 Jul 19;
  15. Trivinho-Strixino, Santos JS, M. Souza Sikora. Electrochemical Synthesis of Nanostructured Materials. Elsevier eBooks. 2017 Jan 1;53–103.
  16. Sharma M, Jain NL, Yashpal. Enablers and Barriers of Circular Economy in Manufacturing Context for Indian Industries. Circular Economy and Sustainability. 2024 Oct 9.
  17. Kar A, Saikia D, Palanisamy S, Pandiarajan N. Effect of fiber loading on the mechanical, morphological, and dynamic mechanical characteristics of Calamus tenuis fiber reinforced epoxy composites. Journal of Vinyl and Additive Technology. 2024 Sep 30.
  18. Sivasubramanian Palanisamy, Ramakrishnan SK, Santulli C, Khan T, Ahmed OS. Mechanical and wear performance evaluation of natural fiber/epoxy matrix composites. BioResources. 2024 Sep 19;19(4):8459–78.
  19. Rajkumar Ramasubbu, Arumugam Kayambu, Sivasubramanian Palanisamy, Nadir Ayrilmis. Mechanical properties of epoxy composites reinforced with Areca catechu fibers containing silicon carbide. BioResources. 2024 Feb 22;19(2):2353–70.
  20. Sivasubramanian Palanisamy, Mayandi Kalimuthu, Santulli C, Palaniappan M, Nagarajan R, Cristiano Fragassa. Tailoring Epoxy Composites with Acacia caesia Bark Fibers: Evaluating the Effects of Fiber Amount and Length on Material Characteristics. Fibers. 2023 Jul 17;11(7):63–3.
  21. Kumar R, Kedar Narayan Bairwa, Reddy DR. Influence of addition of Al2O3 and SiC on tensile and flexural characteristics of epoxy/glass fiber hybrid polymer composite. Materials Today Proceedings. 2023 Jul 1.
  22. Rajesh S, B. VijayaRamnath, C. Elanchezhian, N. Aravind, V. Vijai Rahul, S. Sathish. Analysis of Mechanical Behavior of Glass Fibre/ Al2O3-SiC Reinforced Polymer Composites. Procedia Engineering. 2014 Jan 1;97:598–606.
  23. Shahinoor Alam, Mohammad Asaduzzaman Chowdhury. Characterization of epoxy composites reinforced with CaCO3-Al2O3-MgO-TiO2/CuO filler materials. 2020 Jul 17;59(6):4121–37.
  24. Chopra R, Gupta RK, Kumar M, Akhtar N. Experimental study on mechanical properties of E-Glass fiber reinforced with epoxy resin composite and compare its properties with hybrid composite. Materials Today: Proceedings. 2022 Apr.
Regular Issue Subscription Review Article
Volume 13
Issue 01
Received 30/09/2024
Accepted 05/12/2024
Published 22/01/2025
