A Study on Polymer-Based FinFET Applications and Logic Circuit Implementation with FinFET

Abstract

Nano devices play a crucial role in the semiconductor industry and can work as the solution for the problems like scaling of MOSFET. The FinFET can serve as the substitute of bulk CMOS in nanoscale. It mainly consists of two gate terminals which can be either shorted or kept independent.The shorted gate (SG-FinFET) configuration provides higher Ion and Ioff whereas the Independent Gate (IG-FinFET) configuration reduces the transistor count and also reduces the leakage current. Unique FinFET can be developed by proper choice of its parameters (number of fins, dimensions etc.), materials (for gate, substrate). The flexible electronics moreover has some other requirements that can be fulfilled by the polymer-based FinFET. Polymer can be used in FinFET design in two ways- as substrate and as gate material. This work elaborates the different polymer-based FinFET and their applications based on their characteristics. This paper also includes various FinFET(SG-FinFET and IG-FinFET) based basic logic circuit design such as NAND,NOR,2:1MUX,decoder ,simple Boolean simulated in LTSpice .
