Parametric Study of Fiber-Reinforced Concrete with Partial Cement Substitution Using Fly Ash and Rice Husk Ash

Abstract

This research aims to evaluate the impact of incorporating steel fibers [SF] and partially substituting cement with rice husk ash [RHA] and fly ash [FA] on the properties of concrete. SF were added in different volume fractions [0%, 0.25%, 0.5%, 0.75%, and 1.0%], combined with 10% RHA and 20% FA. Initially, the concrete mix contained 30% FA with no RHA, which was then adjusted to a mix of 15% FA and 15% RHA. The study explores how SF affects workability, compressive strength [CS], bending strength, splitting tensile strength [STS], resistance to acid and chloride attacks, and the overall cost when FA and RHA are used. Experimental findings show enhanced mechanical properties with the inclusion of FA, RHA, and SF. However, when the substitution surpassed 22.5%, the mechanical properties diminished. Furthermore, an increase in RHA content was found to reduce the concrete’s workability.

Browse Figures

❮ ❯

References

1. Agrawal D, Waghe U, Ansari K, Amran M, Gamil Y, Alluqmani AE, et al. Optimization of eco-friendly concrete with recycled coarse aggregates and rubber particles as sustainable industrial byproducts for construction practices. Heliyon. 2024;10[4]:e25923.
2. Chetan D, Aravindan A. An experimental investigation on strength characteristics by partial replacement of rice husk ash and Robo sand in concrete. Mater Today Proc. 2020;33[xxxx]:502–7.
3. Mosaberpanah MA, Umar SA. Utilizing Rice Husk Ash as Supplement to Cementitious Materials on Performance of Ultra High Performance Concrete: – A review. Materials Today Sustainability. 2020;7–8:100030.
4. Songpiriyakij S, Kubprasit T, Jaturapitakkul C, Chindaprasirt P. Compressive strength and degree of reaction of biomass- and fly ash-based geopolymer. Constr Build Mater. 2010;24[3]:236–40.
5. Qureshi LA, Ali B, Ali A. Combined effects of supplementary cementitious materials [silica fume, GGBS, fly ash and rice husk ash] and steel fiber on the hardened properties of recycled aggregate concrete. Constr Build Mater. 2020;263[2020]:120636.
6. Mehta A, Siddique R. An overview of geopolymers derived from industrial by-products. Constr Build Mater. 2016;127:183–98.
7. Kavyateja BV, Reddy PN, Kumar A. Properties of self-compacting concrete modified with ultrafine slag. Research on Engineering Structures and Materials. 2022;8[2]:371–84.
8. Agrawal D, Waghe UP, Raut SP. Performance Evaluation of Rubberized Concrete with the Use of Steel Fibers. In © Springer Nature Singapore Pte Ltd. 2021; 2021. p. 709–17.
9. Abbaszadeh S, Wan Alwi SR, Ghasemi N, Muhamad ID. Removal of Pb[II] from aqueous solution using papaya peel. Regional Symposium on Chemical Engineering [RSCE] and Symposium of Malaysian Chemical Engineering [SOMChE]. 2014;1[October]:1–9.
10. Patil AR, Sathe SB. Feasibility of sustainable construction materials for concrete paving blocks: A review on waste foundry sand and other materials. Mater Today Proc. 2021;43:1552–61.
11. Patil A, Jayale V, Arunachalam KP, Ansari K, Avudaiappan S, Agrawal D, et al. Performance Analysis of Self-Compacting Concrete with Use of Artificial Aggregate and Partial Replacement of Cement by Fly Ash. Buildings [Internet]. 2024 Jan 6;14[1]:143. Available from: https://www.mdpi.com/2075-5309/14/1/143
12. Patil A, Kumar Dwivedi A. Mechanical strength and durability performance of sea water concrete incorporating supplementary cementitious materials in different curing conditions. Mater Today Proc. 2022;65:969–74.
13. Patil A, Kumar Dwivedi A. Mechanical strength and durability performance of sea water concrete incorporating supplementary cementitious materials in different curing conditions. Mater Today Proc. 2022;65:969–74.
14. Agrawal D, Waghe UP, Goel MD, Bagde A. Effect of Micro-silica and Crumb Rubber on Mechanical Properties of Concrete. Engineering Access [Internet]. 2024 Jun 26;10[2]:189–96. Available from: https://ph02.tci-thaijo.org/index.php/mijet/article/view/252912
15. Khaloo A, Raisi EM, Hosseini P, Tahsiri H. Mechanical performance of self-compacting concrete reinforced with steel fibers. Constr Build Mater. 2014;51.
16. Ponikiewski T, Gołaszewski J. The influence of high-calcium fly ash on the properties of fresh and hardened self-compacting concrete and high performance self-compacting concrete. J Clean Prod. 2014;72.
17. IS 269. Ordinary Portland Cement Specification. IS 269-2015, New Delhi, India. 2015;Sixth Revi[December]:01–14.
18. Sandhu RK, Siddique R. Influence of rice husk ash [RHA] on the properties of self-compacting concrete: A review. Vol. 153, Construction and Building Materials. 2017.
19. Zeyad AM. Effect of fibers types on fresh properties and flexural toughness of self-compacting concrete. Journal of Materials Research and Technology. 2020;9[3].
20. Muhammad A, Thienel KC, Sposito R. Suitability of blending rice husk ash and calcined clay for the production of self-compacting concrete: A review. Vol. 14, Materials. 2021.
21. IS 10262. Concrete Mix Proportioning Guidelines. IS 10262-2019, New Delhi, India. 2019;
22. IS 516. Hardened concrete - Methods of test. IS 516-2021, New Delhi, India. 2021;54[August]:1–20.
23. IS 5816. Specification for splitting tensile strength of concrete -Method of Test. IS 5816-1999, New Delhi, India. 1999;1–8.
24. ASTM C1898 20. Standard Test Methods for Determining the Chemical Resistance of Concrete Products to Acid Attack. ASTM International. 2020;[Stage II]:9–10.
25. ASTM: C138/C138M-13. Standard Test Method for Density [Unit Weight], Yield, and Air Content [Gravimetric]. ASTM International. 2013;i:23–6.
26. IS 1199. Methods of sampling and analysis of concrete. IS 1199. 1959;1–49.
27. IS 1199 Part 2 2018. Fresh Concrete Methods of Sampling, Testing and Analysis Part 2 . 2018.
28. ASTM C 138. Standard Test Method for Density.
29. Mohamed HA. Effect of fly ash and silica fume on compressive strength of self-compacting concrete under different curing conditions. Ain Shams Engineering Journal. 2011;2[2]:79–86.
30. Hamza B, Said K, Belkacem M. The influence of recycled steel fibers on self-compacting concrete performance. In: IOP Conference Series: Materials Science and Engineering. 2018.
31. Bureau of Indian Standards IS-456:2000. Plain and Reinforced Concrete- Code of Practice. 2000 [cited 2023 Aug 2]; Available from: www.standardsbis.in
32. BS 1881-122. BSI Standards Publication Testing concrete Part 122 : Method for determination of water absorption. BSI Standards. 2011;1–8.
33. Bureau of Indian Standards IS-516:2021. Hardened Concrete- Method of Test. 2021 [cited 2023 Aug 2]; Available from: www.standardsbis.in
34. IS 1199-3. Fresh Concrete-Methods of Sampling, Testing and Analysis Part 3 Determination of Density of Fresh Concrete [ First Revision ] [Internet]. 2018. Available from: www.standardsbis.in
35. Akinpelu MA, Odeyemi SO, Olafusi OS, Muhammed FZ. Evaluation of splitting tensile and compressive strength relationship of self-compacting concrete. Journal of King Saud University - Engineering Sciences. 2019;31[1].
36. Dhiyaneshwaran S, Ramanathan P, Baskar I, Venkatasubramani R. Study on durability characteristics of self-compacting concrete with fly ash. Jordan Journal of Civil Engineering. 2013;7[3].
