Modelling of The Viscoelastic Composite Curved Panel for The Time Domain Analysis Using TTBDF, β1 / β2−Bathe and Newmark Method

Open Access

Year : 2025 | Volume : 13 | Special Issue 01 | Page : 204 222
    By

    Vishwanil Sarnaik,

  • Mekala Anil,

  • Satyajit Panda,

  • S.Kanaragaj,

  1. Research Scholar, Department of Mechanical Engineering, Indian Institute of Technology Guwahati, Guwahati, Assam, India
  2. Research Scholar, Department of Mechanical Engineering, Indian Institute of Technology Guwahati, Guwahati, Assam, India
  3. Professor, Department of Mechanical Engineering, Indian Institute of Technology Guwahati, Guwahati, Assam, India
  4. Professor, Department of Mechanical Engineering, Indian Institute of Technology Guwahati, Guwahati, Assam, India

Abstract

Viscoelastic materials are extensively used in structures, especially thin-walled structures, for damping. The accurate modelling of the time domain dynamics of the viscoelastic material is essential for appropriately capturing the damping of the viscoelastic material. Various implicit and explicit time integration schemes are available to evaluate time domain response. However, the rightness of the implementation of the time integration scheme to the viscoelastic material model is very essential. In this paper, the non-linear FE model is developed to characterize the time domain behaviour of the composite curved panel. The composite curved panel comprises metal and viscoelastic material. The viscoelastic material is modelled by a four-parameter fractional order derivative model. The time integration method is then coupled with the non-linear FE model and then solved by the Newton-Raphson method to obtain a time domain response. Three different time integration methods such as TTBDF composite method,  Bathe explicit method and the Newmark implicit method are combined with the non-linear FE model and the respective responses are evaluated. The dynamic response of the composite curved panel is studied under the external harmonic force excitation. The responses of the three given time integration methods are compared. All three-time integration methods accurately capture the forcing frequency with slight variation in the displacement responses due to the implementation of the Grunwald formalism.

Keywords: Four-parameter fractional order derivative model, Newmark implicit method, Bathe explicit method, TTBDF composite method

[This article belongs to Special Issue under section in Journal of Polymer and Composites (jopc)]

aWQ6MTk1ODY0fGZpbGVuYW1lOjJiNDM1YzY0LWZpLXBuZy53ZWJwfHNpemU6dGh1bWJuYWls
How to cite this article:
Vishwanil Sarnaik, Mekala Anil, Satyajit Panda, S.Kanaragaj. Modelling of The Viscoelastic Composite Curved Panel for The Time Domain Analysis Using TTBDF, β1 / β2−Bathe and Newmark Method. Journal of Polymer and Composites. 2024; 13(01):204-222.
How to cite this URL:
Vishwanil Sarnaik, Mekala Anil, Satyajit Panda, S.Kanaragaj. Modelling of The Viscoelastic Composite Curved Panel for The Time Domain Analysis Using TTBDF, β1 / β2−Bathe and Newmark Method. Journal of Polymer and Composites. 2024; 13(01):204-222. Available from: https://journals.stmjournals.com/jopc/article=2024/view=187960


Browse Figures

References

  1. Cao XT, Zhang ZY, Hua HX. Free vibration of circular cylindrical shell with constrained layer damping. Applied Mathematics and Mechanics. 2011 Apr; 32:495-506. https://doi.org/10.1007/ s10483-011-1433-7.
  2. Bagley RL, Torvik PJ. Fractional calculus-a different approach to the analysis of viscoelastically damped structures. AIAA journal. 1983 May;21(5):741-8.https://doi.org/10.2514/3.8142.
  3. Schmidt A, Gaul L. Finite element formulation of viscoelastic constitutive equations using fractional time derivatives. Nonlinear Dynamics. 2002 Jul;29:37-55. https://doi.org /10.1023/A:1016552503411.
  4. Deü JF, Galucio AC, Ohayon R. Finite element formulation for a transient dynamic analysis of viscoelastic beams using fractional derivative constitutive equations. InSeventh International Conference on Computational Plasticity; COMPLAS VII 2003 Apr 7. Barcelona, Spain. ⟨hal-03179392⟩.
  5. Enelund M, Josefson BL. Time-domain finite element analysis of viscoelastic structures with fractional derivatives constitutive relations. AIAA journal. 1997 Oct;35(10):1630-7. https://doi.org/10.2514/2.2.
  6. Escobedo-Torres J, Ricles JM. The fractional order elastic-viscoelastic equations of motion: formulation and solution methods. Journal of intelligent material systems and structures. 1998 Jul;9(7):489-502. https://doi.org/10.1177/1045389X980090070.
  7. Padovan J. Computational algorithms for FE formulations involving fractional operators. Computational Mechanics. 1987 Dec;2(4):271-87. https://doi.org/10.1007/BF00296422.
  8. Newmark NM. A method of computation for structural dynamics. Journal of the engineering mechanics division. 1959 Jul;85(3):67-94.https://doi.org/10.1061/JMCEA3.0000098.
  9. Malakiyeh MM, Shojaee S, Hamzehei-Javaran S, Bathe KJ. The explicit β1/β2-Bathe time integration method. Computers & Structures. 2023 Oct 1;286:107092. https://doi.org/10.1016/j.  2023.107092.
  10. Chandra Y, Zhou Y, Stanciulescu I, Eason T, Spottswood S. A robust composite time integration scheme for snap-through problems. Computational Mechanics. 2015 May;55:1041-56.https://doi.org/10.1007/s00466-015-1152-3.
  11. Sahoo SR, Ray MC. Active control of nonlinear transient vibration of laminated composite beams using triangular SCLD treatment with fractional order derivative viscoelastic model. Journal of Dynamic Systems, Measurement, and Control. 2019 Nov 1;141(11):111014. https://doi.org/10.1115/1.4043928.
  12. Galucio AC, Deü JF, Ohayon R. Finite element formulation of viscoelastic sandwich beams using fractional derivative operators. Computational mechanics. 2004 Mar;33:282-91. https://doi.org/10.1007/s00466-003-0529-x.
