Advanced Processing Technologies and Material Properties of Ceramic-Matrix Composites for Structural and Industrial Applications

Open Access

Year : 2024 | Volume : 12 | Special Issue 06 | Page : 138 151
    By

    Madhavi Wagh,

  • Gulshad Nawaz Ahmad,

  • Suvarna Lalit Toke,

  • Gajanan Zumbarlal Jadhav,

  • Rajesh Kumar,

  1. Assistant Professor, School of Science, Sandip University, Nashik, Maharashtra, India
  2. Assistant Professor, Department of Mechanical Engineering, Sandip University Sijoul, Bihar, India
  3. Assistant Professor, Department of Mechanical Engineering, Sandip Institute of Engineering & Management, Nashik, Maharashtra, India
  4. Assistant Professor, Sandip Institute of Technology & Reserch Centre, Nashik, Maharashtra, India
  5. Assistant Professor, Department of Mechanical Engineering, Sandip University Sijoul,, Maharashtra, India

Abstract

Ceramic-matrix composites (CMCs) are becoming more popular as building and industrial materials because they have a unique set of qualities, such as being able to withstand high temperatures and being light and strong. This brief talks about the newest improvements in processing methods and material features that have put CMCs at the top of the list of industrial materials. Using advanced processing methods like chemical vapor infiltration (CVI), polymer infiltration and pyrolysis (PIP), and fast modeling methods like additive manufacturing is a big part of how CMCs are getting better. These techniques allow precise control over the microstructure and improve the performance of CMCs by lowering flaws and making them more regular. Also, experts have come a long way in changing the material qualities of CMCs to fit the needs of different applications. Scientists have improved the strength, resistance to heat shock, and resistance to oxidation in CMCs by fine-tuning the makeup and structure of clay fibers and materials. Better heat conductivity, electrical conductivity, and wear resistance have been achieved by adding useful chemicals and nanoparticles to CMCs. This means that they can be used in more businesses. Improvements in joining and finishing methods have also helped with problems that come up when trying to use CMCs in complicated structures and difficult working conditions. Techniques like soldering, diffusion bonding, and plasma spraying make it easier to put together CMC parts while keeping their strength and performance even in harsh circumstances.

Keywords: Ceramic-matrix composites (CMCs), Processing technologies, Material properties, Structural applications, Industrial applications, Advanced fabrication techniques

[This article belongs to Special Issue under section in Journal of Polymer and Composites (jopc)]

aWQ6MTY4NjkwfGZpbGVuYW1lOmEwY2Y4ZWZhLTEucG5nfHNpemU6dGh1bWJuYWls
How to cite this article:
Madhavi Wagh, Gulshad Nawaz Ahmad, Suvarna Lalit Toke, Gajanan Zumbarlal Jadhav, Rajesh Kumar. Advanced Processing Technologies and Material Properties of Ceramic-Matrix Composites for Structural and Industrial Applications. Journal of Polymer and Composites. 2024; 12(06):138-151.
How to cite this URL:
Madhavi Wagh, Gulshad Nawaz Ahmad, Suvarna Lalit Toke, Gajanan Zumbarlal Jadhav, Rajesh Kumar. Advanced Processing Technologies and Material Properties of Ceramic-Matrix Composites for Structural and Industrial Applications. Journal of Polymer and Composites. 2024; 12(06):138-151. Available from: https://journals.stmjournals.com/jopc/article=2024/view=168703


Browse Figures

References

  1. Yin, J, Xu, J, Ding, W, Su, H. Effects of grinding speed on the material removal mechanism in single grain grinding of SiCf/SiC ceramic matrix composite. Ceram. Int. 2021, 47, 12795–12802.
  2. Liu, Q, Huang, G, Fang, C, Cui, C, Xu, X. Experimental investigations on grinding characteristics and removal mechanisms of 2D–Cf/C-SiC composites based on reinforced fiber orientations. Ceram. Int. 2017, 43, 15266–15274.
  3. Liu, Q, Huang, G, Xu, X, Fang, C, Cui, C. Influence of grinding fiber angles on grinding of the 2D–Cf/C–SiC composites. Ceram. Int. 2018, 44, 12774–12782.
  4. Karakoc, O, Koyanagi, T, Nozawa, T, Katoh, Y. Fiber/matrix debonding evaluation of SiCf/SiC composites using micropillar compression technique. Compos. Part B Eng. 2021, 224, 109–189.
  5. Li, L. Fatigue Life Prediction of Fiber-Reinforced Ceramic-Matrix Composites with Different Fiber Preforms at Room and Elevated Temperatures. Materials 2016, 9, 207.
  6. Qinglong, A.N, Chen, J, Ming, W, Chen, M. Machining of SiC ceramic matrix composites: A review. Chin. J. Aeronaut. 2021, 34, 540–567.
  7. Farías, I, Olmos, L, Jiménez, O, Flores, M, Braem, A, Vleugels, J. Wear modes in open porosity titanium matrix composites with TiC addition processed be spark plasma sintering. Trans. Nonferrous Met. Soc. China 2019, 29, 1653–1664
  8. Gu, J, Lee, S.H, Vu, V.H, Yang, J, Lee, H.S, Kim, J.S. Fast fabrication of SiC particulate-reinforced SiC composites by modified PIP process using spark plasma sintering—Effects of green density and heating rate. J. Eur. Ceram. Soc. 2021, 41, 4037–4047.
  9. Singh, S, Singh, V, Kumari, S, Udayakumar, A, Prasad, V.V. High-temperature flexural strength of I-CVI processed Cf/SiC composites with variable interphases. J. Eur. Ceram. Soc. 2021, 41, 130–135.
  10. Süß, F, Schneider, T, Frieß, M, Jemmali, R, Vogel, F, Klopsch, L, Koch, D. Combination of PIP and LSI processes for SiC/SiC ceramic matrix composites. Open Ceram. 2021, 5, 100056.
  11. Key, T.S, Patel, D.K, Wilks, G.B, Cinibulk, M.K. Modeling the pyrolysis of preceramic polymers: A kinetic study of the polycarbosilane SMP-10. J. Eur. Ceram. Soc. 2021, 41, 6356–6365.
  12. Neuman, E.W, Brown-Shaklee, H.J, Watts, J.L, Hilmas, G, Fahrenholtz, W.G. Case study: Building an ultra-high temperature mechanical testing system. Am. Ceram. Soc. Bull. 2013, 92, 36–38.
  13. Kumar, K.S, Cherusseri, J, Thomas, J. Two-Dimensional Mn3O4 Nanowalls Grown on Carbon Fibers as Electrodes for Flexible Supercapacitors. ACS Omega 2019, 4, 4472–4480.
  14. Braginsky, M, Przybyla, C.P. Simulation of crack propagation/deflection in ceramic matrix continuous fiber reinforced composites with weak interphase via the extended finite element method. Compos. Struct. 2016, 136, 538–545.
  15. Guangwu, F, Long, L, Xiguang, G, Yingdong, S. Finite Element Analysis of the Crack Deflection in Fiber Reinforced Ceramic Matrix Composites with Multilayer Interphase Using Virtual Crack Closure Technique. Appl. Compos. Mater. 2020, 27, 307–320.
  16. Nakazato, N, Kishimoto, H, Park, J.-S. Appropriate thickness of pyrolytic carbon coating on SiC fiber reinforcement to secure reasonable quasi-ductility on NITE SiC/SiC composites. Ceram. Int. 2018, 44, 19307–19313.
  17. Xu, T.-T, Cheng, S, Jin, L.A. High-temperature flexural strength of SiC ceramics prepared by additive manufacturing. Int. J. Appl. Ceram. Technol. 2020, 17, 438–448.
  18. Yin, J, Lee, S.H, Feng, L, Zhu, Y, Liu, X, Huang, Z, Kim, S.Y, Han, I.S. The effects of SiC precursors on the microstructures and mechanical properties of SiCf/SiC composites prepared via polymer impregnation and pyrolysis process. Ceram. Int. 2015, 41, 4145–4153.
  19. Weinmann, M, Kamphowe, T.W, Schuhmacher, J, Müller, K, Aldinger, F. Synthesis and Thermal Behavior of Novel Si−B−C−N Ceramic Precursors. Chem. Mater. 2000, 12, 2112.
  20. Pisch, A, Ferraria, A.M, Chatillon, C, Blanquet, E. Evaporation Behavior of SiC Powder for Single Crystal Growth—An Experimental Study on Thermodynamics and Kinetics. Mater. Sci. Forum 2000, 338–342, 91–94.
  21. Yun, S.I, Nahm, S, Park, S.W. Effects of SiC particle size on flexural strength, permeability, electrical resistivity, and thermal conductivity of macroporous SiC. Ceram. Int. 2022, 48, 1429–1438.
  22. Francis, J. Ceramic Matrix Composites: A Strong and Lightweight Material Solution. Res. Rev. J. Mater. Sci. 2022, 10, 1–2.
  23. Chawla, K.K. Ceramic Matrix Composites. In Composite Materials; Springer: New York, NY, USA, 2012; pp. 249–292.
  24. Shvydyuk, K.O, Nunes-Pereira, J, Rodrigues, F.F, Silva, A.P. Review of Ceramic Composites in Aeronautics and Aerospace: A Multifunctional Approach for TPS, TBC and DBD Applications. Ceramics 2023, 6, 195–230.
Special Issue Open Access Review Article
Volume 12
Special Issue 06
Received 16/05/2024
Accepted 15/07/2024
Published 23/08/2024
