Assembly Process and Performance of A Micro Steam Power Plant

Year : 2025 | Volume : 02 | Issue : 02 | Page : 38 48
    By

    Adeyemo Elijah,

  • Afolabi Samuel,

  • Buliaminu Kareem,

  1. Project Partner, Department of Industrial and Production Engineering, Federal University of Technology, Akure, Nigeria
  2. Project Partner, Department of Industrial and Production Engineering, Federal University of Technology, Akure, Nigeria
  3. Professor, Department of Industrial and Production Engineering, Federal University of Technology, Akure, Nigeria

Abstract

Energy is an indispensable component of modern society, driving everything from industrial processes to household appliances, among the various sources of energy, steam power, a form of heat energy has played a pivotal role in the development of human civilization, paving the way for the Industrial Revolution and subsequent technological advancements. This study focused on the assembly and performance evaluation of a 5 kW steam power plant. The components of the steam power plant including steam generator, turbine and alternator which are readily available were assembled using on-site assembly: partial fabrication method of assembly. The performance evaluation of the assembled power plant was carried out measuring and recording the temperature, pressure and dryness fraction of steam from the steam generator with the maximum temperature, maximum pressure and dryness fraction being 239, 0.3985MPa and 0.93 respectively. The performance evaluation of the steam turbine powered alternator under changeable bed and drive mechanisms was also carried out with the turbine-alternator unit operated with axial coupling, the voltage output, rotational speed and sound level was measured and recorded to be 56V, 1152 rpm and 73dB respectively, the evaluation was also carried out with the turbine-alternator unit operated with transverse connection, the voltage output, rotational speed and sound level was measured and recorded to be 24V, 904 rpm and 71dB respectively. With the results obtained and discussed, it was noticed that the transverse connection of the turbine-alternator unit is less efficient in transferring mechanical energy to electrical output compared to the axial coupling of the unit, making the axial coupling using a flexible flange system a better and plausible power transmission method in the system. A total of Sixty-Three Thousand, Eight Hundred Naira only was spent on the successful assembly of this system

Keywords: Steam power plant, assembly, performance evaluation, turbine-alternator unit, axial coupling.

[This article belongs to International Journal of Industrial and Product Design Engineering ]

How to cite this article:
Adeyemo Elijah, Afolabi Samuel, Buliaminu Kareem. Assembly Process and Performance of A Micro Steam Power Plant. International Journal of Industrial and Product Design Engineering. 2024; 02(02):38-48.
How to cite this URL:
Adeyemo Elijah, Afolabi Samuel, Buliaminu Kareem. Assembly Process and Performance of A Micro Steam Power Plant. International Journal of Industrial and Product Design Engineering. 2024; 02(02):38-48. Available from: https://journals.stmjournals.com/ijipde/article=2024/view=193179


References

  1. Chu, S., & Majumdar, A. (2012). Opportunities and challenges for a sustainable energy future. Nature, 488, 294-303.
  2. Dickinson, J. (2011). Court Politics and the Earl of Essex 1589–1601. Routledge.
  3. Hills, R. L. (1989). Power from Steam: A History of the Stationary Steam Engine. Cambridge University Press.
  4. (2022). Climate Change 2022: Mitigation of Climate Change. Contribution of Working Group III to the Sixth Assessment Report of the Intergovernmental Panel on Climate Change. Cambridge University Press. https://doi.org/10.1017/9781009157926.008
  5. McKendry, P. (2002). Energy production from biomass (Part 1): Overview of biomass. Bioresource Technology, 83(1), 37–46. https://doi.org/10.1016/S0960-8524(01)00118-3
  6. Nag, P. K. (2008). Power Plant Engineering (2nd ed.). Tata McGraw-Hill Publishing Company Ltd.
  7. Okoroigwe, E. C., Saffron, C. M., & Kamdem, P. D. (2014). Characterization of palm kernel shell for materials reinforcement and water treatment. National Centre for Energy Research and Development, University of Nigeria; Department of Biosystems and Agricultural Engineering, Michigan State University; Department of Packaging, Michigan State University.
  8. Oladosu, K. O., Kareem, B., Akinnuli, B. O., & Asafa, T. B. (2016). Optimisation of ash yield from combustion of palm kernel shell and selected additives (Al₂O₃, CaO, and MgO) using D-optimal design. Leonard Electronic Journal of Practices and Technologies, 28(1), 9-18.
  9. Osafehinti, S. I., & Ayodeji, O. Z. (2011). Modeling of 1.0 MW-h combustible waste fuel steam thermal station: A panacea for rural/off-grid areas’ electrification. Journal of Energy Technologies and Policy, 8(3).
  10. Panwar, N. L., Kaushik, S. C., & Kothari, S. (2011). Role of renewable energy sources in environmental protection: A review. Department of Renewable Energy Sources, College of Technology and Engineering, Maharana Pratap University of Agriculture and Technology; Center for Energy Studies, Indian Institute of Technology – Delhi.
  11. Saidur, R., Ahamed, J. U., & Masjuki, H. H. (2010). Energy exergy and economic analysis of industrial boilers. Energy Policy, 38, 2188–2197.
  12. Sharma, L. J. K., & Singh, S. K. (2013). A study on the democratic style of leadership. International Journal of Management and Information Technology, 3, 54-57. https://doi.org/10.24297/ijmit.v3i2.1367.
  13. Smil, V. (2017). The dark side of growth. World Energy, 10(37), 10-13.
  14. Woodruff, E. B., Lammers, H. B., & Lammers, T. F. (2010). Steam Plant Operation (8th ed.). The McGraw-Hill Companies. Available: www.digitalengineeringlibrary.com. Accessed: September 7, 2010.
Regular Issue Subscription Original Research
Volume 02
Issue 02
Received 05/11/2024
Accepted 27/11/2024
Published 01/12/2024
