Bomkesh Bhoi,
Bidya Bedant Joshi,
Pranati Purohit,
- Student, School of Physics, Gangadhar Meher University, Sambalpur, Odisha, India
- Student, School of Physics, Gangadhar Meher University, Sambalpur, Odisha, India
- Assistant Professor, School of Physics, Gangadhar Meher University, Sambalpur, Odisha, India
Abstract document.addEventListener(‘DOMContentLoaded’,function(){frmFrontForm.scrollToID(‘frm_container_abs_127148’);});Edit Abstract & Keyword
Piezoelectric energy harvesters (PHE) have drawn significant interest as a method of harvesting environment energy to power because of its compatibility and high energy density. Integrating piezoelectric energy harvesters into wireless sensor networks, Internet of Things (IoT)) devices, and wearable electronics enhances their functionality and also increases sustainability. This integration can be lead to the development of self-powered devices that can operate continuously without the need for external power sources. The problem occurs while using PEH are the low level of harvested power and extraction of maximum power. The extracted output power need rectification and the output voltage need to be regulated. To overcome these problems piezoelectric energy harvester or transducer cannot be used alone to harvest mechanical energy. To increase the output voltage and power it is necessary to choose a piezoelectric material, piezoelectric transducer as well as an electric circuit. In this paper, we discuss different circuits such as Switch only rectifier circuit, Voltage multiplier based energy harvesting circuit, Synchronised Switch Harvesting on Inductor (SSHI) and Synchronous Electrical Charge Extraction (SECE) to harvest piezoelectric energy. The design and optimization of the circuits were done by using Multisim software. Physically, a stack transducer is developed by using PZT materials and integrated into the electrical circuit. The output voltage of 1.2 V to 1.9 V is recorded by using the human thumb impression to piezoelectric element and this voltage is sufficient to glow an LED bulb.
Keywords: Energy Harvesting, Piezoelectric Material, PZT, Transducer, Electric Circuit.
Bomkesh Bhoi, Bidya Bedant Joshi, Pranati Purohit. Energy Harvesting Circuits with Piezoelectric Material: Design, Integration, and Optimization. Journal of Polymer and Composites. 2024; ():-.
Bomkesh Bhoi, Bidya Bedant Joshi, Pranati Purohit. Energy Harvesting Circuits with Piezoelectric Material: Design, Integration, and Optimization. Journal of Polymer and Composites. 2024; ():-. Available from: https://journals.stmjournals.com/jopc/article=2024/view=0
References
document.addEventListener(‘DOMContentLoaded’,function(){frmFrontForm.scrollToID(‘frm_container_ref_127148’);});Edit
1. Dikshit T, Shrivastava D, Gorey A, et al. Energy Harvesting via Piezoelectricity. BVICAM’s International Journal of Information Technology. 2010; 2 (2). 2. Chen Z, Law M, Mak P, et al. Fully Integrated Inductor-Less Flipping-Capacitor Rectifier for Piezoelectric Energy Harvesting. IEEE Journal of Solid-State Circuits. 2017; 52(12): 3168-80p. 3. Priya S. Advances in energy harvesting using low profile piezo electric transducers. Journal of Electroceramic. 2007; 19(1): 167–84p. 4. Dinmohammadi F, Han Y, Shafiee M. Predicting Energy Consumption in Residential Buildings Using Advanced Machine Learning Algorithms. Energies, 2023;16(9): 3748. 5. Bhoi B, Purohit P. A brief review on the status of binary and ternary relaxor-PT materials. Materials Today: Proceedings. 2022; 62: 5298–301p. 6. Hwang SJ, Jung HJ, Kim JH. Designing and Manufacturing a Piezoelectric Tile for Harvesting Energy from footsteps. Current Applied Physics. 2015; 15 (6): 669–74p. 7. Gareh S, Kok BC, Yee MH, et al. Optimization of the Compression-Based Piezoelectric Traffic Model (CPTM) for Road Energy Harvesting Application. Int. J. Renew. Energy Res. 2019; 9: 1272–82p.
Journal of Polymer and Composites
| Volume | |
| Received | 26/07/2024 |
| Accepted | 13/11/2024 |
| Published | 10/12/2024 |
