Open Access
Abhishek T.K.*
Ram Vishal
Jini Raj R.
- Assistant Professor Department of Aeronautical Engineering, Nitte Meenakshi Institute of Technology, Bangaluru Karnataka India
- Assistant Professor Department of Aeronautical Engineering, Nitte Meenakshi Institute of Technology, Bangaluru Karnataka India
- Assistant Professor Department of Aeronautical Engineering, Nitte Meenakshi Institute of Technology, Bangaluru Karnataka India
Abstract
The new era of unmanned aerial vehicles (UAV) started long back. The purpose of this project was to make a new innovative approach to the designing of UAVs for better use in the field of surveillance and commercial photography and videography. The UAV was designed in such a way that holds the camera connected to a wireless transmission system, this feeds the live information to the ground station. This UAV housing with many sensors such as GPS and IMU sensors. CATIA v5 tool was used to design this UAV and Autodesk flow was used for simulation and testing. This UAV can be used in military and civilian applications such as aerial photography, videography, field surveillance, disaster relief, and many more. However, most of the UAVs in the present market are expensive and have more weight. To overcome these issues, we introduced a new lightweight and cost-effective UAV which can be able to perform surveillance and feed the data in real-time to the user. Our team did deeper background research on UAV and come up with a new UAV approach that can have 3105 grams of weight with 5 to 10 KM of range and 45min of endurance. This gives strong competition to many UAVs which exist in the market.
Keywords: UAV, GPS, Autodesk flow, Inertial Measurement Unit (IMU)
[This article belongs to Special Issue under section in Journal of Polymer and Composites(jopc)]
Browse Figures
References
1. Lee, K. (2004). Development of unmanned aerial vehicle (UAV) for wildlife surveillance
(Doctoral dissertation, University of Florida).
2. Bowman, R. (2004). Large Unmanned Vehicles. Volume 9, 55-56.
3. Lennon, A. (2005). R/C Model Aircraft Design. Air Age Media Inc., United State of America.
4. Jung, S. (2004). Design and Development of Micro Air Vehicle: Test Bed for Vision-Based
Control (Doctoral dissertation, MS thesis, Mechanical and Aerospace Engineering Department,
University of Florida).
5. Erick Purwanto, Jeremy Smith Lightweight UAV Image Segmentation Model Design with Edge
Feature Aggregation (, Conference: 2023 International Conference on Platform Technology and
Service.)
6. Abdelrahman, M. M., Elnomrossy, M. M., & Ahmed, M. R. (2009, May). Development of mini
unmanned air vehicles. In International Conference on Aerospace Sciences & Aviation
Technology.
7. Parsch, A. (2004). AeroVironment FQM-151 Pointer. Directory of US Military Rockets and
Missiles.
A New Design and CFD Analysis of UAV for Military and Other Applications Abhishek et al.
8. Tuton Mallick, Mohammad Ariful Islam Bhuyan, Mohammed Saifuddin Munna.;2016
International Conference on Innovations in Science, Engineering and Technology (ICISET),
Design & implementation of an UAV (Drone) with flight data record
9. Thome, D. M., & Thome, T. M. (2000). Radio-controlled model airplanes: inexpensive tools for
low-level aerial photography. Wildlife Society Bulletin, 343-346.
10. F.B. da Silva S.D. Scott M.L. Cummings ; Design Methodology for Unmannded Aerial Vehicle
(UAV) Team Coordination.
11. Jones, G. P. (2003). The feasibility of using small unmanned aerial vehicles for wildlife research
(Doctoral dissertation, University of Florida).
12. Raymer, D. P. (1992). Aircraft design. A conceptual approach. Ian R. McAndrew, Elena
Visnehvskaya, and Kenneth L. Witcher Establishing Angle of Attach for NACA 6412 Twin-
Wing on Take-off Downwash Influences on Lift and Drag
13. Zakaria, M. Y., Abdallah, M. M., & Elshafie, M. A. (2012, May). Design and production of small
tailless unmanned aerial vehicle (SAKR 2). In Proceedings of the 15th AMME Conference.
14. Viieru, D., Albertani, R., Shyy, W., & Ifju, P. G. (2005). Effect of tip vortex on wing
aerodynamics of micro air vehicles. Journal of Aircraft, 42(6), 1530-1536.
Journal of Polymer and Composites
| Volume | 11 |
| Special Issue | 13 |
| Received | November 27, 2023 |
| Accepted | January 6, 2024 |
| Published | March 11, 2024 |
