Effect of hybrid plant-based cutting fluid in turning operation of EN19 steel and modelling of heat transfer equation for multiple phase colloids

Open Access

Year : 2024 | Volume :11 | Special Issue : 12 | Page : 175-185
By

Dwaipayan Gupta

Bikash Choudhuri

Ruma Sen

  1. Doctor of Philosophy Student Department of Mechanical Engineering West Bengal India
  2. Associate Professor Department of Mechanical Engineering, Institute of Engineering and Management West Bengal India
  3. Assistant Professor Department of Mechanical Engineering West Bengal India

Abstract

This article describes a project where an alternative to conventional Mineral Oil (MO) based cutting fluids is tried on the turning operation of steel samples. The deposit of petroleum is getting depleted day by day, the pollution due to fossil fuel is increasing exponentially and petroleum is getting more and more expensive. Due to these reasons, nonpetroleum (MO) based alternative cutting fluids have been in business for quite a while. There is still active research going on to find a good alternative to replace MO-based cutting fluids. The article demonstrates the experimental result of non-mineral oil based cutting fluid composed of Brassica nigra (mustard) seed oil and helianthus annuus(sunflower) seed oil mixed with water, suspended Graphite particles and lecithin is applied on EN 19 steel subject to turning operation by high-speed steel turning tool. The effect of the cutting fluid on friction, average cutting temperature, average cutting tool life, and roughness of the finished surface, are studied in this project. A heat transfer model has been described which may be a good fit in this case. A significant development in the machined surface quality has been encountered alongside a fall in average cutting temperature.

Keywords: Hybrid Cutting fluids; Heat transfer; turning; surface finish; Cutting temperature

[This article belongs to Special Issue under section in Journal of Polymer and Composites(jopc)]

How to cite this article: Dwaipayan Gupta, Bikash Choudhuri, Ruma Sen. Effect of hybrid plant-based cutting fluid in turning operation of EN19 steel and modelling of heat transfer equation for multiple phase colloids. Journal of Polymer and Composites. 2024; 11(12):175-185.
How to cite this URL: Dwaipayan Gupta, Bikash Choudhuri, Ruma Sen. Effect of hybrid plant-based cutting fluid in turning operation of EN19 steel and modelling of heat transfer equation for multiple phase colloids. Journal of Polymer and Composites. 2024; 11(12):175-185. Available from: https://journals.stmjournals.com/jopc/article=2024/view=137390

Full Text PDF Download

Browse Figures

References

  1. Ogedengbe TS, Okediji AP, Yussouf AA, Aderoba OA, Abiola OA, Alabi IO, Alonge OI. The effects of heat generation on cutting tool and machined workpiece. In Journal of Physics: Conference Series 2019 Dec 1 (Vol. 1378, No. 2, p. 022012). IOP Publishing.
  2. D’Addona DM, Conte S, Teti R, Marzocchella A, Raganati F. Feasibility study of using microorganisms as lubricant component in cutting fluids. Procedia CIRP. 2020;88:606–11.
  3. Avila RF, Abrao AM. The effect of cutting fluids on the machining of hardened AISI 4340 steel. Journal of Materials Processing Technology. 2001 Dec 20;119(1-3):21–6.
  4. Khan MM, Dhar NR. Performance evaluation of minimum quantity lubrication by vegetable oil in terms of cutting force, cutting zone temperature, tool wear, job dimension and surface finish in turning AISI-1060 steel. Journal of Zhejiang University-SCIENCE A. 2006 Nov;7(11):1790–9.
  5. Costa ES, Silva MB, Machado AR. Burr produced on the drilling process as a function of tool wear and lubricant-coolant conditions. Journal of the Brazilian Society of Mechanical Sciences and Engineering. 2009;31:57–
  6. Singh NK, Singh Y, Sharma A, Paswan MK, Singh VK, Upadhyay AK, Mishra VR. Performance of CuO nanoparticles as an additive to the chemically modified Nicotiana Tabacum as a sustainable coolant-lubricant during turning EN19 steel. Wear. 2021 Dec 15;486:204057.
  7. Zedan MH, Abdulmunem KA. Tribological performance of mustard seeds oil under different loads using pin-on-disk Tribotester. The Iraqi Journal For Mechanical And Material Engineering. 2018 Dec;18(4).
  8. Rodrigues JR, Neves TD, da Silva MB, Martins KC, dos Santos Ribeiro JR, Cunha AP. Study of the application of sunflower oil in the process of drilling ABNT 1045 steel< b. Acta Scientiarum. Technology. 2014 Apr 4;36(2):257–62
  9. Singh R. Progress of environment friendly cutting fluids/solid lubricants in turning-A review. Materials Today: Proceedings. 2021 Jan 1;37:3577–80.
  10. Bibin C, Devarajan Y, Bharadwaj A, Patil PY. Detailed analysis on nonedible waste feedstock as a renewable cutting fluid for a sustainable machining process. Biomass Conversion and Biorefinery. 2023 Feb;13(4):3405–13.
  11. Ladakhi TY, Sharma S, Pradhan BB, Tiwary AP. Vegetable based cutting fluid for metal cutting operation: A review. InAIP Conference Proceedings 2023 Jun 1 (Vol. 2786, No. 1). AIP Publishing.
  12. Alaba ES, Kazeem RA, Adebayo AS, Petinrin MO, Ikumapayi OM, Jen TC, Akinlabi ET. Evaluation of palm kernel oil as cutting lubricant in turning AISI 1039 steel using Taguchi-grey relational analysis optimization technique. Advances in Industrial and Manufacturing Engineering. 2023 May 1;6:100115.
  13. Liu X, Zhao J, She Y, Liu Y. Development history, current situation and prospect of international vegetable oil-based hydraulic oil. In E3S Web of Conferences 2023 (Vol. 385). EDP Sciences.
  14. Sani AS, Zamri Z, Radzi PH, Sabri AM, Talib N. Modified Tamanu Plant-Based Oil From Pahang Malaysia as Biodegradable Metalworking Fluids. Materials Today: Proceedings. 2023 Jan 1;75:39–45.
  15. Heat and Mass Transfer. India: Tata McGraw-Hill, 2011.
  16. Klang V, Valenta C. Lecithin-based nanoemulsions. Journal of Drug Delivery Science and Technology. 2011 Jan 1;21(1):55–76.
  17. Bueschelberger HG, Tirok S, Stoffels I, Schoeppe A. Lecithins. Emulsifiers in food technology. 2014 Dec 15:21–60.
Special Issue Open Access Original Research
Volume 11
Special Issue 12
Received December 21, 2023
Accepted January 5, 2024
Published April 1, 2024
Views: 49
