Strength Investigation on Butt Welded Polymer Tubes

Open Access

Year : 2024 | Volume :11 | Special Issue : 13 | Page : 74-84
By

    Ram Vishal Gandham

  1. Srikanth H.V

  2. Abhishek T.K.

  3. Mahendra K.

  4. Anirudh P.

  5. Rahul B.

  1. Assistant Professor, Department of Aeronautical Engineering, Nitte Meenakshi Institute of Technology, Karnataka, India
  2. Associate Professor, Department of Aeronautical Engineering, Nitte Meenakshi Institute of Technology, Karnataka, India
  3. Assistant Professor, Department of Aeronautical Engineering, Nitte Meenakshi Institute of Technology, Karnataka, India
  4. Student, Department of Aeronautical Engineering, Nitte Meenakshi Institute of Technology, Karnataka, India
  5. Student, Department of Aeronautical Engineering, Nitte Meenakshi Institute of Technology, Karnataka, India
  6. Assistant Professor, Department of Aeronautical Engineering, Nitte Meenakshi Institute of Technology, Karnataka, India

Abstract

The purpose of this study is to examine instances in which pipes and butt welds are subjected to
unintended stresses, resulting in fractures or full destruction. The behavior of radial force
(perpendicular to the OX axis) in two circumstances is seen, and we conclude which of the two
examples has more flaws. The two circumstances will be examined from an analytical, theoretical,
and experimental standpoint, leading to some key findings of this type of incident. The analytical
component involves a rigorous investigation of the structural design, material properties, and stress
distribution within the given contexts. This is complemented by a theoretical exploration, wherein
mathematical models and simulations are employed to predict the response of pipes and butt welds to
various stress scenarios. Experimental analyses are conducted to validate the theoretical predictions
and provide real-world insights into the behavior of these components under unexpected stress
conditions.

Keywords: Finite element, Polyethylene, Butt weld, Polymer tube, Welding, axial strength, compressive strength.

[This article belongs to Special Issue under section in Journal of Polymer and Composites(jopc)]

How to cite this article: Ram Vishal Gandham, Srikanth H.V, Abhishek T.K., Mahendra K., Anirudh P., Rahul B. Strength Investigation on Butt Welded Polymer Tubes jopc 2024; 11:74-84
How to cite this URL: Ram Vishal Gandham, Srikanth H.V, Abhishek T.K., Mahendra K., Anirudh P., Rahul B. Strength Investigation on Butt Welded Polymer Tubes jopc 2024 {cited 2024 Feb 29};11:74-84. Available from: https://journals.stmjournals.com/jopc/article=2024/view=133898

Full Text PDF Download

Browse Figures

References

  1. Avrigean E. Study on Temperature Distribution in the Jointing Fittings for Polyethylene Natural Gas Pipes. 2015 3rd International Conference on Recent Trends in Materials and Mechanical Engineering (ICRTMME 2015), January 15-16, 2015, Auckland, New Zealand.
  2. Balan, M. L. Contributii la utilizarea procedeului de sudare cap la cap a tevilor de polietilena destinate transportului si distributiei gazelor naturale. Doctoral thesis. Sibiu.
  3. Oleksik, V., Pascu, A.M. Proiectarea optimala a maşinilor si utilajelor, “Lucian Blaga” University Publishing House, Sibiu, 2007.
  4. Avrigean E. Theoretical and experimental research on the assembly welding of polyethylene fitting-PEHD PE100. Joint International Conference of Doctoral and Post-Doctoral Researchers, Craiova, 12-13 September 2014.
  5. M. Duse, I. Bondrea, E. Avrigean. Fabricatia integrata de calculator CIM a transmisiilor cardanice. “Lucian Blaga” University Publishing House, Sibiu, 2003.
  6. Murariu, A.C. Influenta imperfectiunilor imbinarilor sudate ale structurilor din polietilena de inalta densitate. Doctoral thesis. Timisoara, 2008.
  7. LUPU, N.I. Conducte din polietilena in sistemele de distributie. “Lucian Blaga” University Publishing House, Sibiu, 2000.
  8. Radu, GH. N., Munteanu, M. GH., Bit, C. S., Rezistena materialelor şi teoria elasticităii, Vol. III. Macarie Publishing House, Targoviste,
  9. Bowman J. 1991. Fusion joining of cross-linking polyethylene pipe: Proceedings of Advances in joining plastics and composites.
  10. Measuring Elementary Load Cases with Strain Gauges, by K. Hoffmann, vd 73002e, Hottinger Baldwin Messtechnik gmbh, Darmstadt.
  11. ISO 12176-2:2000-Plastics pipes and fittings-Equipment for fusion jointing polyethylene systems-Part 2: Electrofusion
  12. I. Gerasimov, E.V. Danzanova, G.V. Botvin, Testing of welded joints of polypropylene pipes, Vestnik ESSUTM. 66 (2017) 38-42.
  13. P. Starostin, M.A. Vasil’eva, E.V. Danzanova, O.A. Ammosova, Butt welding of polyethylene pipes at low temperatures, Welding International. 27 (2013) 318-320.
  14. E.V. Danzanova, Issues of quality control of welded joints of polyethylene pipes for gas pipelines, Oil and Gas Business. 1 (2009) 1-9

Special Issue Open Access Original Research
Volume 11
Special Issue 13
Received November 28, 2023
Accepted December 6, 2023
Published February 29, 2024
