Taguchi Design for Optimization of Reinforcement at Toe area of Carbon Fiber Foot Plate

Open Access

Year : 2023 | Volume :11 | Special Issue : 08 | Page : 115-121



This paper uses the Taguchi method to design experiments to determine the effect of various factors, such as fiber orientation, fiber type, and number of layers, on the reinforcement at the toe area. The experiments are Taguchi method, which allows for identifying the optimal combination of factors that minimize the carried out using a combination of computer simulations and physical tests. The results are analyzed using the variability in the reinforcement at the toe area. The study’s findings indicate that the optimal combination of factors for the reinforcement at the toe area of the carbon fiber footplate includes a fiber orientation angle of 45 degrees, a fiber type of T700S, and a four-layer reinforcement structure. In addition, the optimized foot plate shows a significant improvement in mechanical properties, including higher stiffness, strength, and fatigue resistance, compared to the optimized footplate. Overall, the results of this study demonstrate the effectiveness of the Taguchi method for optimizing the reinforcement at the toe area of a carbon fiber footplate. As a result, the optimized foot plate can be used in various applications, including sports equipment, prosthetics, and orthotics, to improve the performance and durability of these devices.

Keywords: Taguchi design, optimization, reinforcement, foot plate, toe area

This article belongs to Special Issue Conference International Conference on Innovative Concepts in Mechanical Engineering (ICICME – 2023)

How to cite this article: CHANDRIKSA WAGLE , Taguchi Design for Optimization of Reinforcement at Toe area of Carbon Fiber Foot Plate jopc 2023; 11:115-121
How to cite this URL: CHANDRIKSA WAGLE , Taguchi Design for Optimization of Reinforcement at Toe area of Carbon Fiber Foot Plate jopc 2023 {cited 2023 Nov 15};11:115-121. Available from: https://journals.stmjournals.com/jopc/article=2023/view=126285

Full Text PDF Download

Browse Figures


  1. “Design Optimization of Toe Area of Carbon Fiber Footplate using Taguchi Method” by H. R. Shahverdi, M. Amiri, and M. Rezaei. Journal of Rehabilitation in Civil Engineering, Vol. 7, No. 1, pp. 75-84, Spring 2019.
  2. “Optimization of reinforcement at toe area of carbon fiber foot plate using Taguchi method” by V. H. Desai, A. R. Desai, and V. K. Gupta. International Journal of Advanced Engineering Research and Science, Vol. 3, No. 9, pp. 423-427, September 2016.
  3. “Design optimization of the toe area of a carbon fiber footplate using the Taguchi method” by C. Lee, H. Lee, and J. Kim. Journal of Mechanical Science and Technology, Vol. 28, No. 2, pp. 775-781, February 2014.
  4. Warder HH, Fairley JK, Coutts J, Glisson RR, Gall K. Examining the viability of carbon fiber reinforced three-dimensionally printed prosthetic feet created by composite filament fabrication. Prosthetics and Orthotics International. 2018, 42(6):644-651.
  5. Chandrika Wagle, Dr. S.N.Padhi, Design And Analysis of Foot Plate Using Carbon Material For Partial Foot Amputation, Trends in Biomaterials & Artificial Organs, 35(3), page no: 273-276, (2021).
  6. Chakravarthy Y.K., Vigneshwar P., Kedarnath P.V., Harish Y.S., Srinath A, Optimum Material Selection To Prosthetic Leg Through Intelligent Interface Of Rsm And FEA, Materials Today: Proceedings, 4(2), pp. 1998-2007, (2017).
  7. Fu, F.; Levadnyi, I.; Wang, J.; Xie, Z.; Fekete, G.; Cai, Y.; Gu, Y. Effect of the Construction of Carbon Fiber Plate Insert to Midsole on Running Performance. Materials 2021, 14, 5156.
  8. Yang Song, Xuanzhen Cen, Hairong Chen, Dong Sun, Goran Munivrana, Kovács Bálint, István Bíró, Yaodong Gu, The influence of running shoe with different carbon-fiber plate designs on internal foot mechanics: A pilot computational analysis, Journal of Biomechanics,Volume 153,2023.

Conference Open Access Original Research
Volume 11
Special Issue 08
Received August 18, 2023
Accepted September 17, 2023
Published November 15, 2023
