Open Access
Aloke Kanjilal
Abstract
Regarding targeted treatment, hadron therapy is beneficial than conventional radiotherapy based on X rays/gamma rays due to characteristic energy loss profile of energetic charged particle during ion matter interaction. In this regard, dose monitoring and its precise measurement with spatial accuracy are very crucial. Thermoluminescence (TL) based thin film radiation dosimeter has the potential to serve this purpose. In hadron therapy, use of swift carbon ion beam is found to be best due to both physical and biological benefits. Regarding swift ion irradiation, although electronic energy loss (Se) dominates over nuclear energy loss (Sn), still the possibility of Sn induced lattice defects formation cannot be completely ruled out. Therefore, efficiency/sensitivity of dosimeter could be changed. Aluminium oxide (Al2O3) is one of the promising materials in the field of dosimetry. For the use of Al2O3 based radiation dosimeter for ion beam dosimetry, it is necessary to understand the effect of swift carbon ion irradiation on Al2O3 thin films. In this article, the effect of irradiation of swift carbon ion beam on radiation efficiency/sensitivity of radio frequency magnetron grown alumina (Al2O3) is presented and the feasibility of Al2O3 based radiation dosimeter is discussed.
Keywords: Radiation hardness, Ion beam dosimetry, Thermoluminescence, Al2O3 thin film, Swift carbon ion beam
[This article belongs to Special Issue under section in Journal of Polymer and Composites(jopc)]
Browse Figures
References
1.
McKeever SWS, Thermoluminescence of solids: Cambridge University Press; 1988.
2.
Duragkar A, Muley A, Pawar NR, et al. Versatility of thermoluminescence materials and radiation dosimetry–A review. Luminescence. 2019 Nov;34(7): 656–65.
3.
Sawakuchi GO, Yukihara EG, McKeever SW, et al. Relative optically stimulated luminescence and thermoluminescence efficiencies of Al2O3:C dosimeters to heavy charged particles with energies relevant to space and radiotherapy dosimetry. Journal of Applied Physics. 2008 Dec 15;104(12):124903.
4. Karger CP, Jäkel O, Palmans H, Kanai T. Dosimetry for ion beam radiotherapy. Physics in Medicine & Biology. 2010 Oct 15;55(21):R193.
5. Ahmed MF, Shrestha N, Ahmad S, et al. Demonstration of 2D dosimetry using Al2O3 optically stimulated luminescence films for therapeutic megavoltage x-ray and ion beams. Radiation Measurements. 2017 Nov 1;106:315–20.
6. Damulira E, Yusoff MN, Omar AF, Mohd Taib NH. A review: Photonic devices used for dosimetry in medical radiation. Sensors. 2019 May 14;19(10):2226.
7. Krimmer J, Angellier G, Balleyguier L, et al. A cost-effective monitoring technique in particle therapy via uncollimated prompt gamma peak integration. Applied Physics Letters. 2017 Apr 10;110(15):154102.
8. Akselrod MS, Kortov VS, Kravetsky DJ, Gotlib VI. Highly sensitive thermoluminescent anion-defective alpha-Al203: C single crystal detectors. Radiation Protection Dosimetry. 1990 Jul 1;32(1):15–20.
9. Kanies B, Hayes R, Yang G. Thermoluminescence and optically stimulated luminescence response of Al2O3 coatings deposited by mist-chemical vapor deposition. Radiation Physics and Chemistry. 2022 Feb 1;191:109860.
10. Bhowmick S, Pal S, Singh A, et al. Carbon doping-induced defect centers in anodized alumina with enhanced optically stimulated luminescence. Journal of Materials Science: Materials in Electronics. 2021 Apr;32:10635–43.
11. Ghamnia M, Jardin C, Bouslama M. Luminescent centres F and F+ in α-alumina detected by cathodoluminescence technique. Journal of electron spectroscopy and related phenomena. 2003 Nov 1;133(1–3):55–63.
12. Bhowmick S, Pal S, Das D, et al. Carbon doping controlled thermoluminescent defect centers in nanoporous alumina for ion beam dosimetry. Journal of Applied Physics. 2018 Oct 7;124(13):134902.
13. Bhowmick S, Pal S, Singh A, et al. Revealing carbon mediated luminescence centers with enhanced lifetime in porous alumina. Journal of Applied Physics. 2019 Oct 28;126(16):164904.
14. Pal S, Bhowmick S, Khan SA, et al. Annealing temperature-driven near-surface crystallization with improved luminescence in self‐patterned alumina films. Journal of Materials Science: Materials in Electronics. 2021 May;32:11709–18.
15. Ziegler JF, Ziegler MD, Biersack JP. SRIM–The stopping and range of ions in matter (2010). Nuclear Instruments and Methods in Physics Research Section B: Beam Interactions with Materials and Atoms. 2010 Jun 1;268(11–12):1818–23.
16. Geiß OB, Krämer M, Kraft G. Efficiency of thermoluminescent detectors to heavy charged particles. Nuclear Instruments and Methods in Physics Research Section B: Beam Interactions with Materials and Atoms. 1998 Aug 1;142(4):592–8.
17. Saini CP, Barman A, Satpati B, et al. Defect-engineered optical bandgap in self-assembled TiO2 nanorods on Si pyramids. Applied Physics Letters. 2016 Jan 4;108(1):011907.
Journal of Polymer and Composites
| Volume | 11 |
| Special Issue | 07 |
| Received | August 14, 2023 |
| Accepted | August 31, 2023 |
| Published | November 13, 2023 |
