Tropospheric Variation of Point Refractivity Gradient and Geo-climatic Factor over a Coastal Location in Tropical Nigeria

Year : 2024 | Volume :15 | Issue : 02 | Page : 29-43
By

Okikiade Adewale Layioye,

  1. Student Department of Physics, Federal University of Technology Akure Nigeria

Abstract

Accurate assessment of refractivity gradient and Geo-climatic factor is crucial for maintaining reliable radio signal propagation in clear-air environments. These parameters are essential for determining the fade margin necessary to ensure a stable and effective wireless radio link, given the unstable nature of the atmosphere through which the signals travel. It is crucial to have accurate knowledge of these characteristics, particularly at microwave antenna heights of around 70 meters, in order to sustain a functional line-of-sight (LOS) link even in the most adverse weather circumstances. The lack of adequate studies on this topic for Lagos made the investigation necessary. This study utilized meteorological data, including surface air temperature, dew point temperature, and relative humidity, obtained from the European Centre for Medium-Range Weather Forecasts (ECMWF) archive over a period of six years. The point refractivity gradient at 70 meters and refractive conditions were estimated for Ikeja, Lagos State, which is a coastal city within tropical Nigeria. The study’s findings demonstrate that the Geo-climatic factor and point refractivity gradient in the studied area change with the seasons. Specifically, for Ikeja and its environs, the research found that the average point refractivity gradient and Geo-climatic factor at 70 meters above ground level are -196.30 N-units/km and 1.06E-04, respectively. These findings indicate that radio waves propagating in this region at the specified altitude are likely to experience super refraction under both rainy and clear-air atmospheric conditions. In addition, wet months show high variability of refractivity gradient of about -167.828 N-units/km due to increase in the water vapour in the atmosphere compared to the dry periods with low variability of about -196.296 N-units/km. Also, the average values of the Geo-climatic factor in the wet season are 8.66774E-05 and that of the dry season is 0.000133. This suggests that extremely poor radio propagation condition is expected to take place within the dry months, especially in November. This study highlights the significant influence of meteorological parameters such as temperature, pressure, and humidity on the quality of services provided by inter-terrestrial radio communication links, including GSM networks, Wide Area Networks (WAN), and radio and TV broadcasts. The insights gained from this research are particularly valuable for radio engineers involved in the design and configuration of inter-terrestrial microwave links in Ikeja and its environs, facilitating optimal quality of service even during adverse weather conditions.

Keywords: Geo-climatic factor, radio communication, electromagnetic waves, GSM networks, Wide Area Networks (WAN)

[This article belongs to Journal of Remote Sensing & GIS(jorsg)]

How to cite this article: Okikiade Adewale Layioye. Tropospheric Variation of Point Refractivity Gradient and Geo-climatic Factor over a Coastal Location in Tropical Nigeria. Journal of Remote Sensing & GIS. 2024; 15(02):29-43.
How to cite this URL: Okikiade Adewale Layioye. Tropospheric Variation of Point Refractivity Gradient and Geo-climatic Factor over a Coastal Location in Tropical Nigeria. Journal of Remote Sensing & GIS. 2024; 15(02):29-43. Available from: https://journals.stmjournals.com/jorsg/article=2024/view=167728

Browse Figures

References

  1. Bettouche, Yamina, Basile L. Agba, and Ammar B. Kouki. (2014). “Geoclimatic factor and point refractivity evaluation in Quebec-Canada.” General Assembly and Scientific Symposium (URSI GASS), 2014 XXXIth URSI. IEEE, 2014.
  2. Dinc, Ergin, and Ozgur Akan. (2014). “Beyond-line-of-sight communications with ducting layer.” Communications Magazine, IEEE 52.10 (2014): 37-43.
  3. Odedina P.K. and Afullo T.J. (2007), “Use of Spatial Interpolation Technique for the Determination of the Geoclimatic Factor and Fade Depth Calculation for Southern Africa,” Proceedings of IEEE AFRICON conference 2007 ISBN: 0 – 7803 – 8606 – X. IEEE Catalogue number: 04CH37590C, September 26 – 28, 2007, Namibia.
  4. Olsen R. L. and Segal B. (1992), “New techniques for predicting the Multipath Fading Distribution on VHF/ UHF/SHF Terrestrial Line-of- Sight Links in Canada Canada Journal of Elec. And Comp. Engineering, Vol. 17, No 1., pp. 11-23.
  5. Olsen R. L. and Tjelta T. (1999), “Worldwide Techniques for predicting the Multipath Fading Distribution on Terrestrial L.O.S. Links: Background gation, Vol. 47, January 1999, pp. 157-170.
  6. Adediji AT, Mandeep JS, Ismail M. Meteorological characterization of effective earth radius factor (k-factor) for wireless radio link over Akure, Nigeria.l MAPAN- Journal of Metrology Society of India. 2014; 29:131. DOI:10.1007/s12647-013-0074-9.
  7. Karimian AC, Yardim, C, Hodgkiss WS, Gerstoft P, Barrios AE. Estimation of radio refractivity using a multiple angle clutter model, Radio Sci. 47, RS0M07. DOI:10.1029/2011RS004701
  8. OJO, OL, et al. “Estimation Of Clear-Air Fades Depth Due To Radio Climatological Parameters For Microwave Link Applications In Akure, Nigeria.” International Journal of Engineering 7.03 (2015): 8269.
  9. Asiyo, Mike Omondi, and Thomas Joachim Odhia Afullo. “Statistical estimation of fade depth and outage probability due to multipath propagation in Southern Africa.” Progress In Electromagnetics Research B 46 (2013): 251-274.
  10. Tjelta T., Oslen R.L. and Martin A.L. (1990), “Systematic Development of New Multivariable Techniques for Predicting the Distribution of Multipath Fading on Terrestrial Microwave Link,” IEEE Transaction on antennas and Propagation, vol.38, pp. 1650-1665.
  11. Etokebe I. J., Uko M. C., and Chinwe I. U. (2016), “Determination of Refractivity Gradient and Geoclimatic Factor Using Radiosonde Data and Inverse Distance Weighting Spatial Interpolation for Missing Data”. International Journal of Systems Science and Applied Mathematics 1 (2016) 76. doi: 10.11648/j.ijssam.20160104.17
  12. Oluwafemi I. B. and Olla M. O. (2021). “Estimation of Geoclimatic Factor for Nigeria through Meteorological Data,” European Journal of Electrical Engineering and Computer Science, Vol. 5, No. 3, pp 41-44, DOI: http://dx.doi.org/10.24018/ejece.2021.5.3.191.
  13. Grabner, M., and V. Kvicera. “Introduction to project of refractive index measurement in Prague.” Antennas and Propagation, 2003.(ICAP 2003). Twelfth International Conference on (Conf. Publ. No. 491). Vol. 2. IET, 2003.
  14. ITU-R, “Propagation data and prediction methods required for the design of terrestrial line-of-sight systems”, Recommendation of ITU-R P.530-14, Geneva, 2012.
  15. Serdega, V., and G. Ivanovs. “Refraction seasonal variation and that influence on to GHz range microwaves availability.” Elektronika ir Elektrotechnika 78.6 (2015): 39-42.
  16. IUT-Radio Communication Assembly: “Propagation data and prediction methods required for the design of terrestrial line-of-sight systems,” International Telecommunication Union, Geneva, Switzerland, IUT-R P.530-16; 2015.
  17. ITU-R Rec 834-4: Effects of Tropospheric Refraction on Radiowave Propagation, International Telecommunication Union, ITU 2003.
  18. J. Afullo, M. O. Adongo, T. Motsoela, T & D. F. Molotsi, “Refractivity gradient and k-factor in Botswana”, in Proceedings of the Third Regional Workshop on Radio Communications in Africa: Radio Africa ’99. The Transactions of the SA Institute of Electrical Engineers (2001) 107.
  19. R. Bean, & E. J. Dutton, “Radio Meteorology”, National Bureau of Standard Monographs, US department of commerce. (1996) 132.
  20. Akpootu DO, Iliyasu MI. Estimation of tropospheric radio refractivity and its variation with meteorological parameters over Ikeja, Nigeria. Journal of Geography, Environment and Earth Science International. 2017;10(1):1-12.
  21. U. Ezeh & M. C. Obeta & N. C. Raymond, “Variations in the sequences of daily rainfall across Nigeria”, Arab Journal of Geosciences, 9 (2016) 681. DOI 10.1007/s12517-016-2719-9.
  22. Adedeji, E. U. Utah & T. E. Sombos, “Monthly Variation and Annual Trends of Rainfall across Major Climatic Zones in Nigeria”, IOSR Journal of Applied Physics (IOSR-JAP) 10 (2018) 15.
  23. J. Olaniran & G. N. Sumner, “A Study of Climatic Variability in Nigeria Based on the Onset, Retreat, and Length of the Rainy Season”, International Journal of Climatology 9 (1989) 253.
  24. B. Lawal, S.E. Falodun & J.S. Ojo, “Temporal evolution of atmospheric parameter-profiling on rain height over two geoclimatic regions in Nigeria. Journal of Atmospheric and Solar-Terrestrial Physics” 211 (2020) 105482. https://doi.org/10.1016/j.jastp.2020.105482.
  25. Owolabi IE, Williams VA. Surface radio refractivity patterns in Nigeria and the Southern Cameroon. Journal of West African Science Association. 1970; 1:3–17.
Regular Issue Subscription Original Research
Volume 15
Issue 02
Received June 10, 2024
Accepted July 7, 2024
Published July 10, 2024
